Service Manual Mitsubishi SL-Series diesel engines
Version 08/2004
ENGLISH
SPECIFICATIONS SERVICE DATA
190 / 195
Alternator
Regulated voltage at 20°C (68°F) 14.7 ± 0.3 V —
Output
charac-
teristics
(at
operating
tempe-
rature)
At 2500
rpm
Terminal
voltage
13.5 V —
Test.
Current 33 A min. —
At 500
rpm
Terminal
voltage
13.5 V —
Current 47 A min. —
Brush length — Wear limit line Replace.
Resistance in glow plug 0.55 Ω — Replace.
Item Standard Limit Correction-Remarks
