TROUBLESHOOTING OVERHAUL INSTRUCTIONS
24 / 195
6.2.4 Problem 4: Black exhaust smoke
1. Items to be checked ahead of time
• Clogged air cleaner
• Poor quality fuel
2. Inspection procedure
Are valve clearance and injection timing correct? No Z
Make adjustment to the
clearance and timing.
VYes
Is injection nozzle discharge pattern normal? Is injection pressure correct
(not too high)?
No Z
Make adjustment to the
nozzles.
V Yes
Is compression pressure correct? No Z
Check valves, piston rings
and cylinder head gasket.
V Yes
Fuel injection pump is faulty.

Mitsubishi S3L2 Specifications

General

Engine Model	S3L2
Aspiration	Naturally aspirated
Cooling System	Water-cooled
Displacement	1.318 L
Bore x Stroke	78 mm x 92 mm
Starting System	Electric starter
Lubrication System	Forced lubrication by trochoid pump
