3.Rotate the screen glass so that the rotation knob and the display of angle counter is counted
in the plus direction. Revolve the screen glass to adjust the cross hairs of screen glass with
the index once again.
4.The angle counter is corrected, when the display unit switching key and the angle display
zero-set key are pressed in the condition of step 3 simultaneously. (The display is 360
°00’ or
360.00
°.)
• The correction value after the correction is preserved even if the power switch is turned OFF.
• The correction is not possible, when the screen glass is rotated in the negative direction.
3 - 12 No.99MBA043A
