OPERATION
(10) Feed wire over the drive roller into the outlet (11) Close down the top roller bracket
and guide tube, Push the wire through approx 150mm. clip the pressure arm into place
with a medium amount of pressure
applied.
(12) Remove the gas nozzle and contact (13) Press and hold the manual wire button
tip from the front end of the mig torch. to feed the wire down the torch cable
through to the torch head.
(14) Fit the correct size contact tip over the (15) Fit the gas nozzle to the torch head.
wire and fasten tightly into the tip holder.
