MKS Mass-Flo 1179A - Dimensions; Figure 1: Outline Dimensions of the Type 1179 MFC and Type 179 MFM

Chapter Two: Installation Setu
p
27
Dimensions
Note
All dimensions are listed in inches with millimeters referenced in
parentheses.
Controller Gain
Zero Adjust
5.49 (139.5) with
Type "D" connector
5.30 (134.6) with recessed
P.C. Ed
g
e Board connector
or
0.50 (12.7)
3.00 (76.2)
Swa
g
elok 4-VCR compatible 4.88 (123.9) shown
Swa
g
elok 4-VCO compatible 4.56 (115.8)
" Swa
g
elok compatible 4.44 (112.7)
¼
Figure 1: Outline Dimensions of the Type 1179 MFC and Type 179 MFM
Note
The method used to measure the overall length of the unit varies with the
type of fitting. For VCR and VCO compatible fittings, the unit is
measured from mating face to mating face. For Swagelok compatible
fittings, the unit is measured from fitting end to fitting end (less nut).
