6
4.2 External Mode
In the External Input Mode the user can’t make any flash rate
adjustments. The fl ash rate is a function of the input signal. This mode
is used to synchronize the fl ash to an external event (for example, from
an optical sensor) to stop or freeze motion. The fl ash will be triggered on
the rising or falling edge (menu selectable) of the external input pulse.
The input jack enables an external signal to trigger the strobe. Inserting
a plug into the input jack will automatically put the strobe into the
External Mode. When the strobe is in the External Input Mode, EXT
will be displayed.
When an external input is applied to the unit and the strobe is put in the
Tachometer Mode, the unit will read the signal from the external input
(sensor) and display the reading on the LCD display without fl ashing
the lamp. When there is a valid external signal the on target indicator
will turn on. The strobe will not fl ash in the Tach (Tachometer) Mode.
To exit the External mode, remove the device from the input jack and
the strobe will be put back into the Internal Mode.
4.3 Charging Mode
The Charging Mode is when the strobe has the battery recharger plugged
into it. The strobe will not operate while charging. The status of the
charge is indicated by the LED on the charger. While charging the LED
on the charger is RED; when the charge is complete the LED will turn
GREEN. USE ONLY THE CHARGER SUPPLIED WITH THE
STROBE - Model LBC-U.
5.0 SETUP MENU OPTIONS
To enter the Setup Mode it is necessary to press the MENU button twice.
The fi rst press will enter the x2 /2 mode as described in section 4.1.2; the
