MONARCH INSTRUMENT PLS - 1.0 Introduction

1
MENU
EXT
1/4-20
Bushing
Charger
Jack
Battery
Cover
Input
Jack
Output
Jack
1.0 INTRODUCTION
The Pocket LED Strobe (PLS) is a rugged, portable battery powered LED
(Light Emitting Diode) stroboscope used for inspection and to stop motion to
determine the speed of rotating objects. The unit is ergonomically designed
for comfortable hand held operation or it may be mounted on a tripod using
the integral ¼ -20 UNC bushing on the underside of the unit.
Figure 1 Pocket LED Strobe
