20. Electrical Specification
MCL recommend a 24V, 4A power supply.
24 volt motor version
Table 5: Electrical Specification
Electrical Specification
Supply Voltage +24V
Typical Operating Current/No Load 0.35A
Typical Operating Current/Max Load 0.9A
Surge Current/Start Up and Reverse 3.6A
Typical Payout Rate 8 to 10 coins per second
20.1 Coin Payout:
Table 6: Coin Payout Rate
Mode Rate
Multi coin payout 8 - 10 coins per second approx.
Single coin payout 2 coins per second approx.
