5. Mechanical Features
5.1 Hopper Dimensions
The hoppers overall dimensions, mounting arrangement, coin entry and exit points are
detailed in Figure 1. Note that, when used in the side exit mode, the rear of the motor
protrudes from the rear of the casing, within the overall dimensions of the hopper envelope.
5.2 Hopper Weight
570 Grams
5.3 Coin Size Range
Hoppers can be configured to pay out coins in the diameter range 16.25 - 31.0mm, and
within the thickness range 1.25-3.20mm. However, each coin needs to be qualified on an
individual coin basis.
For further information on qualification of coins, please contact Money Controls Technical
Services Department.
5.4 Coin Capacity
The coin capacity of the hopper is between 200 and 1000 depending on their physical size.
Table 1: Coin Capacities
Coin
Diameter
(mm)
Thickness
(mm)
SCH2
STD
SCH2
Extended
£2 28.40 2.50 189 252
£1 22.50 3.10 235 314
50p new 27.30 1.80 282 376
20p 21.40 1.80 459 613
10p 24.50 1.83 349 465
5p 18.00 1.73 679 905
2p 25.90 1.80 316 421
1p 20.25 1.43 652 870
Note: these capacities are subject to a +/- 10% error.
