29. Appendix G
The Unencrypted Hopper
Serial Compact Hopper Mk2 is available in an unencrypted version.
The unencrypted serial compact hopper can be used without any knowledge of the encryption
algorithm used on the standard ‘encrypted’ product. The ccTalk commands have been kept
identical to minimise changes to software between products.
To find out which product you have, use ccTalk header 244, ‘Request product code’.
Product Encryption ? Returned Product Code
Serial Compact Hopper Mk2 Yes SCH2
Serial Compact Hopper Mk2 No SCH2-NOENCRYPT
“Dispense hopper coins”
ccTalk command Header 167.
Transmitted data: <variable> [no. of coins]
Received data: [event counter] or NAK
Where <variable> = 8 bytes of data.
This data can be 1-1-1-1-1-1-1-1, 1-2-3-4-5-6-7-8 or any 8 random bytes of data.
NOTE: The competition tend to only require 3 bytes of data to be sent which is the
internal serial number and this is used as the <variable> in the “transmitted data”, to
payout the coins.
Note that a ‘Request cipher key’ command is still required prior to each dispense but the
result can be thrown away as it is not needed. If the request cipher key is not sent then a
NAK will be returned when a dispense is attempted.
Example Command Sequence
1. Command 'Enable hopper'
TX = 003 001 001 164 165 178
RX = 001 000 003 000 252 = ACK
2. Command 'Request cipher key'
TX = 003 000 001 160 092
RX = 001 008 003 000 097 162 057 066 112 230 076 011 201
The 8 data bytes can be ignored as they are not needed.
3. Command 'Dispense hopper coins'
TX = 003 009 001 167 000 000 000 000 000 000 000 000 005 071
RX = 001 001 003 000 008 243
This examples dispenses 5 coins.
