KEYPAD OPTIONS
∗
∗∗
∗190 Keypad 2 Device Address 17 [0] [0]
VISTA-20PMT V20P Partition/ Sound
Partition: V15P Enable
Enter the desired option for the keypad’s home partition.
For Touchscreen device usage
0 = disable
1 = partition 1
2 = part. 2
3 = part. 3 (common)
For Remote Services device usage
5 = part. 1 (auto-stay arm disabled)
6 = part. 2 (auto-stay arm disabled)
7 = part. 3 (common; auto-stay arm disabled)
Sound: Enter the desired sound option for this keypad.
0 = no suppression
1 = suppress arm/disarm and E/E beeps
2 = Suppress chime beeps only
3 = suppress arm/disarm, E/E, and chime beeps
VISTA-15PMT
Enable:
For Touchscreen device usage
0 = disable
1 = enable
For Remote Services device usage
5 = auto-stay arm disabled
Sound: Enter the desired sound option for this keypad.
0 = no suppression
1 = suppress arm/disarm and E/E beeps
2 = Suppress chime beeps only
3 = suppress arm/disarm, E/E, and chime beeps
Note for Remote Services Devices: If using the Remote
Services feature of the communication device, select an
option 5-7 (option 5 for VISTA-15PMT), depending on the
partition the Remote Services device is associated with
(these options automatically disable auto-stay arming
when the system is armed from the respective Remote
Services device). Refer to the communication device’s
installation instructions for details on enabling the Remote
Services feature.
Partition Sound
Enable
∗
∗∗
∗191 Keypad 3 Device Address 18 [0] [0]
See field ∗190 for entries.
∗
∗∗
∗192 Keypad 4 Device Address 19 [0] [0]
See field ∗190 for entries.
∗
∗∗
∗193 Keypad 5 Device Address 20 [0] [0]
See field ∗190 for entries.
∗
∗∗
∗194 Keypad 6 Device Address 21 [0] [0]
See field ∗190 for entries.
∗
∗∗
∗195 Keypad 7 Device Address 22 [0] [0]
See field ∗190 for entries.
∗
∗∗
∗196 Keypad 8 Device Address 23 [0] [0]
See field ∗190 for entries.
∗
∗∗
∗197 Exit Time Display Interval [2]
0 = no display; 1-5 = seconds between display refresh
If enabled, keypads display the exit time remaining after
arming the system, updated at the interval selected (i.e. if
the exit delay is 30 seconds and “2” is selected in this field,
the keypad display refreshes every 2 seconds, displaying
30, 28, 26, 24, etc.).
An interval greater than “1” may be necessary for some
older keypads to allow users time to enter key presses
between display updates.
NOTE: If enabled and using only 2-digit fixed-word keypads
(e.g., 6150RF), do not set exit delay time greater than 96
seconds. Using a longer delay time may cause end-user
confusion because 2-digit display keypads cannot display
times greater than “99.” If longer exit time is required by the
installation, it is recommended that the Exit Time Display
option be disabled (“0”).
TOUCH SCREEN DEVICE NOTE: If using more than one
touch screen device (e.g., 6270, Symphony) with the
system, leave field *197 Exit Time Display Interval set to the
default value “0.” The 6270 automatically displays remaining
exit time in one-second increments.
∗
∗∗
∗198 Display Partition Number [1]
(VISTA-20PMT; for Alpha Display Keypads)
0 = no; 1 = yes (partition no. appears on Alpha Display)
If selected, the partition number is displayed in the upper-left
corner of the display. This is useful when using the GOTO
partition function.
∗
∗∗
∗199 ECP Fail Display [0]
0 = 3-digit display (“1” + device address)
1 = 2-digit fixed-display as “91”
Select “0” if using Alpha keypads and/or 3-digit Fixed-Word
Display keypads. ECP faults will display “1” plus the device
address (00-15) of device causing the fault (e.g., faults on
device 07 display as “107”).
Select “1” if using 2-digit Fixed-Word Display keypads (e.g.,
certain 6128 series keypads). If selected, ECP faults for all
devices will display as “91” on 2-digit displays, and “191” on
3-digit or Alpha keypads.
To Next Page
