– 16 –
WIRELESS KEY PROGRAMMING TEMPLATES
(press the [D] key from *58 Menu mode Summary Screen)
This procedure programs the wireless keys, but a key is not active for arming/disarming until it is assigned to a user
number (see
System Operation
section, Assigning Attributes Command in the Installation Instructions).
TEMPLATE ?
Enter desired template number 1–6 (see chart below), then press
[∗] to continue.
To exit the Template screen, press [#]. The system returns to the
*58 Menu mode Summary Screen.
TEMPLATE SUMMARY
L 01 02 03 04
T 23 22 21 23
The selected template is displayed.
The top line represents loop numbers, the bottom line represents
each loop’s zone type.
Press [∗] to accept template and continue.
PARTITION (VISTA-20PMT)
Enter the partition (1, 2) in which the key is to be active. Press [∗]
to continue.
ENTER START ZONE
The system displays the lowest zone number of the highest available
consecutive 4-zone group.
To start at a different zone number, enter the zone desired, and press
[∗]. If the system has four consecutive zones beginning with that zone,
the zone number is displayed. If not, the system will again display a
suggested zone that can be used.
If the required number of consecutive zones is not available at all, the
system will display “00”.
Press [∗] to accept.
Continue to the INPUT S/N (serial number/loop number) and XMIT TO
CONFIRM prompts described earlier in the *56 Menu Mode section.
IMPORTANT: When confirmed, the key is not active for
arming/disarming until it is assigned to a user number (using the
assigning attributes command, attribute “4”). See System Operation
section in Installation Instructions.
When done, the keypad beeps three times and the display returns to
the ENTER START ZONE prompt to let you enter the starting zone for
the next wireless key.
To quit this mode and return to *58 Menu mode, enter 00 at this
prompt and press [∗].
Wireless Key Predefined Default Templates
For 5804
Loop Function Zone Type
For 5804BD
Loop Function Zone Type
TEMPLATE 1 1 No Response 23 TEMPLATE 4 1 No Response 23
2 Disarm 22 2 No Response 23
3 Arm Away 21 3 Arm Away 21
4 No Response 23 4 Disarm 22
TEMPLATE 2 1 No Response 23 TEMPLATE 5 1 No Response 23
2 Disarm 22 2 Arm Stay 20
3 Arm Away 21 3 Arm Away 21
4 Arm Stay 20 4 Disarm 22
TEMPLATE 3 1 24-hour audible 7 TEMPLATE 6 1 24-hour audible 7
2 Disarm 22 2 Arm Stay 20
3 Arm Away 21 3 Arm Away 21
4 Arm Stay 20 4 Disarm 22
∗
∗∗
∗57 FUNCTION KEY PROGRAMMING
(press
∗
∗∗
∗
57 while in Data Programming mode) The Function Key Worksheet is on page 29.
The system provides the ability to program each of the four keypad function keys to perform one of 12 system operations. The
end user can then activate the function by simply pressing and holding the programmed key for 2 seconds. Typical functions
(listed below) include single-button arming, turning lights on/off, or single-button paging.
To assign emergency key functions (function key option “00”), first program the respective emergency zone number (95 for
“A” key, 96 for “C” key, 99 for “B” key) with the desired zone type using ∗56 (or ∗58) Zone Programming mode, then use ∗57
Function Key menu mode to assign the desired key.
To use a function key to activate a relay action (∗57 Menu mode key function 07), use ∗79 Menu mode to map the output, and
use ∗80 Menu mode to define the output’s action; select system operation type “66.”
To use a function key for a user macro, use ∗57 menu mode to activate the desired key, then define the actual macro
functions using the user code + [#] + [6] [6] command.
PRESS KEY TO PGM
Press the desired function key to be programmed, A-D, then
press [∗] to continue.
When done, press 0 to exit this mode and return to data field
mode.
NOTE: A key programmed as a function key is no longer
available to be used as an end-user macro key or panic key.
321
654
987
#0
*
READY
INSTANT
MAX
OFF
CODE
AWAY
TEST
CHECK
STAY
BYPASS
A
B
C
D
keypad_keys-00-001-V0
PARTITION (VISTA-20PMT)
Enter the partition (1-3) in which this function key will be active.
KEY "A" FUNC
Enter the desired function for this key:
00 = For the Function key selected, the function will be as follows
(default):
If A selected = Zone 95 (emergency key, same as [1] [∗] pair)
If B selected = Zone 99 (emergency key, same as [∗] [#] pair)
If C selected = Zone 96 (emergency key, same as [3] [#] pair)
If D selected = Single-button paging
01 = Single-button paging (sends a 999-9999 message to pager)
02 = Display time
03 = Arm AWAY (reports as User 00 if closing reports are enabled)
04 = Arm STAY (reports as User 00 if closing reports are enabled)
05 = Arm NIGHT-STAY (reports as User 00 if closing reports enabled)
06 = Step Arming
(arms STAY, then NIGHT-STAY if enabled, then AWAY)
07 = Output Device Command (for device programmed as system
operation type 66 in *80 Menu Mode)
08 = Communication Test (sends Contact ID code 601)
09 -12= Macro Keys 1-4 respectively (defined by [#] [6] [6] command)
NOTE: Macros 11-12 apply to VISTA-20PMT only
Press [∗] to continue; returns to key number prompt with the next
function key letter displayed.
