– 2 –

TABLE OF CONTENTS

PROGRAMMING MODE COMMANDS.................................................................................................3

DATA FIELD PROGRAMMING FORM..................................................................................................4

CONFIGURABLE ZONE TYPES WORKSHEETS............................................................................... 13

∗

∗∗

∗56 ZONE PROGRAMMING MENU MODE ........................................................................................14

∗

∗∗

∗58 EXPERT ZONE PROGRAMMING MODE.....................................................................................15

WIRELESS KEY PROGRAMMING TEMPLATES...............................................................................16

∗

∗∗

∗57 FUNCTION KEY PROGRAMMING...............................................................................................16

OUTPUT DEVICE PROGRAMMING GENERAL INFORMATION (*79/*80 Menu Mode)....................17

∗

∗∗

∗79 RELAY/POWERLINE CARRIER DEVICE PROGRAMMING MENU MODE.................................17

∗

∗∗

∗80 OUTPUT FUNCTION MENU MODE.............................................................................................18

∗

∗∗

∗81 ZONE LIST MENU MODE ............................................................................................................19

∗

∗∗

∗82 ALPHA DESCRIPTOR MENUMODE............................................................................................20

ALPHA VOCABULARY LIST (For Entering Zone Descriptors).......................................................21

SETTING SCHEDULES ......................................................................................................................22

AVS SYSTEM ENABLE and QUICK PROGRAMMING COMMANDS................................................23

SETTING THE REAL-TIME CLOCK......................................................................................................2

∗

∗∗

∗29 COMMUNICATION DEVICE MENU MODE (Pass-Through Programming)............................... 24

ZONE TYPE DEFINITIONS.................................................................................................................25

UL NOTICES.......................................................................................................................................26

SIA QUICK REFERENCE GUIDE .......................................................................................................26

UPLOADING/DOWNLOADING VIA THE INTERNET..........................................................................23

WORKSHEET for SCHEDULES.........................................................................................................27

WORKSHEET for ∗

∗∗

∗56 ZONE PROGRAMMING..................................................................................28

WORKSHEET for ∗

∗∗

∗57 FUNCTION KEY PROGRAMMING.................................................................29

WORKSHEET for ∗

∗∗

∗79 RELAY/POWERLINE CARRIER DEVICE PROGRAMMING ..........................29

WORKSHEET for ∗

∗∗

∗81 ZONE LIST PROGRAMMING.........................................................................29

WORKSHEET for ∗

∗∗

∗80 OUTPUT FUNCTION PROGRAMMING..........................................................30

TABLE OF DEVICE ADDRESSES......................................................................................................31

5800 SERIES TRANSMITTER INPUT LOOP IDENTIFICATION.........................................................31

SETTING THE REAL-TIME CLOCK

IMPORTANT: The Real-Time Clock must be set before the end of the installation.

NOTE: All partitions must be disarmed before the date/time can be set.

1. Master Code + [#] + [6] [3]

2. Press [∗] when the time/date is displayed.

A cursor appears under the first digit of the hour.

To move cursor ahead, press [

∗

]. To go back, press [#].

• Enter the 2-digit hour setting.

• Enter the 2-digit minute setting.

• Press [1] for PM or [2] for AM.

• Enter the last two digits of the current year.

• Enter the 2-digit month setting.

• Enter the 2-digit day setting.

3. To exit, press [∗] when cursor is at the last digit, or wait 30 seconds.
