– 29 –
WORKSHEET for ∗
∗∗
∗57 FUNCTION KEY PROGRAMMING
Option
Function
A
P1 P2 com
B
P1 P2 com
C
P1 P2 com
D
P1 P2 com
Comments
01 Paging
02 Time Display
03 Arm AWAY
04 Arm STAY
05 Arm NIGHT-STAY
06 Step Arming
07 Device Activation Device:
08 Comm. Test
09 Macro Key 1 Assign each macro key to only a single partition. †
10 Macro Key 2 Assign each macro key to only a single partition. †
11 Macro Key 3 Assign each macro key to only a single partition. †
12 Macro Key 4 Assign each macro key to only a single partition. †
00 Emergency Keys: zone 95 zone 99 zone 96 paging
Personal Emergency n/a
Silent Alarm n/a
Audible Alarm n/a
Fire n/a
Emergency Keys: A = paired keys [1] / [∗] (zone 95); B = paired keys [∗] / [#] (zone 99); C = paired keys [3] / [#] (zone 96)
† There are only four macros system-wide.
WORKSHEET for ∗
∗∗
∗79 RELAY/POWERLINE CARRIER DEVICE PROGRAMMING
(Must program before using *80)
OUTPUT TYPE
OUTPUT TYPE (09-16 apply to VISTA-20PMT only)
Relay X10
Relay X10
Output
No.
Module
Addr.
Pos
(1-4)
Unit
No.
Description
Output
No.
Module
Addr.
Pos
(1-4)
Unit
No.
Description
01
09
02
10
03
11
04
12
05
13
06
14
07
15
08
16
17
On-Board Trigger 1 norm output =
18
On-Board Trigger 2 norm output =
WORKSHEET for ∗
∗∗
∗81 ZONE LIST PROGRAMMING
Fill in the required data on the worksheet below and follow the procedure in the installation manual as you enter the
data during the displays and prompts that appear in sequence.
NOTE: Record desired zone numbers below, noting that a list may include
any
or
all
of system's zone numbers.
List No. Used For… Contains These Zones…
01 General Purpose (GP)
02 General Purpose
03 Chime-by-Zone or GP (see field *26 for Chime-by-Zone option)
04 Cross Zones
NOTE: Cross zoning takes effect only after Exit Delay expires. See field *85 for Timer option.
05 Night-Stay Zones or GP
06 Dial Delay Disable (see field *50 for Dial Delay Disable option)
07 Unlimited Reports (see field *93 for Unlimited Reports option)
08 General Purpose
09 Zones activating pager 1
10 Zones activating pager 2
11 Zones activating pager 3 (VISTA-20PMT)
12 Zones activating pager 4 (VISTA-20PMT)
