OUTPUT DEVICE PROGRAMMING GENERAL INFORMATION (*79/*80 Menu Mode)
Output Devices: The VISTA-20PMT system supports up to 16 relays and/or Powerline Carrier devices (X-10 devices)
plus 2 built-in trigger outputs in any combination. These 18 “outputs” are assigned to system-wide output
numbers (01-18). Use *79 Menu Mode to assign output numbers and map them to device addresses.
The VISTA-15PMT supports 8 relays and 2 built-in trigger outputs (total 10 outputs).
Output Functions: The system also provides installer-defined output functions, which can be assigned to any of the physical
outputs. Therefore, the action of any one of the outputs can be based on as many of these defined
functions as desired. This lets a single relay or X-10 device perform many functions.
The control supports: V20PMT = up to 48 defined functions; V15PMT = up to 24 functions
Use *80 Menu Mode to define output functions.
WARNING: Relays and output devices are not recommended for life safety applications.
NOTE: When navigating the *79 and *80 menus: The [
✱
] key is used to accept an entry and advance to the next prompt.
The [#] key is used to revert back to the last question to check or change an entry. Press [
✱
] to go forward again.
Programming Output Devices
1. Use *79 Menu Mode to assign module and output numbers and map them to device addresses.
NOTE: You must map output devices using *79 Menu Mode before you can use *80 menu Mode.
2. Use *80 Menu Mode to create output definitions, which control the output devices, if desired.
3. Use *81 Zone List Menu mode to define zone lists for use with output devices if the device action is based on more than
one zone.
• To program a device for manual activation (user code + [#] [7] / [#] [8] + 2-digit device number) or for scheduled automatic
activation, simply map the device using *79 Menu mode.
• To program a device to automatically activate upon a system event (or function key), use *79 Menu mode to map the device,
then use *80 Menu mode to define the automated device action.
∗
∗∗
∗79 RELAY/POWERLINE CARRIER DEVICE PROGRAMMING MENU MODE
(press
∗
∗∗
∗
79 while in Programming mode) The *79 Device Mapping Worksheet is on page 29.
Use this menu to assign Relay Module device addresses and specific relay numbers, and Powerline Carrier unit numbers. The
system is based on predefined module addresses for 4204 and 4229 modules. Refer to the table shown at the “Module
Address” prompt and set the modules’ addresses (via module DIP switches) accordingly.
The following table shows how these outputs are identified.
Output Identification
This output… is identified by…
Relays the Relay Module’s device address and the relay position on that module (i.e. the physical relay
number, 1-4, on that module).
X-10 Device a house ID (entered in data field *27) and the unit number of the device.
Built-in Outputs the output number assigned, 17 for Trigger 1 and/or 18 for Trigger 2.
ENTER OUTPUT NO.
01-18 = VISTA-20PMT relays/X-10;
01-08, 17, 18 = VISTA-15PMT relays/X-10
[∗] to continue
This is the logical (or reference) relay number as used in the
system. Relays and X-10 devices are numbered 01-16; the on-
board triggers are numbered 17 and 18 and can be programmed
for inverted output, if required.
OUT NORM LOW (appears only for triggers 17/18)
0 = no (standard default); sets the output level normally high
1 = yes; sets the output normally low (can be used for resetting 4-
wire smoke detectors)
[∗] to return to Output Number prompt
Output Trigger 17 can be used for resetting 4-wire smoke
detectors by connecting it to the negative power terminal of the
smoke detector, selecting 1 at this prompt, and setting as zone
type 54, fire zone reset, in *80 Menu mode.
After entry, display returns to Output Number prompt. Use *80
Menu mode to program the function of the trigger.
OUTPUT TYPE
0 = delete; 1 = 4204/4229 relay (skip to “B” prompt); 2 =
Powerline Carrier device (skip to “A” prompt)
[∗] to continue.
“A” (if X-10 was selected)
UNIT No.
Enter the unit code (01-16, set at the device).
[∗] to return to the Output Number prompt continue
“B” (if relay was selected)
MODULE ADDR
Enter the predefined address for this module (07-15; see Table of
Device Addresses).
Make sure the module’s DIP switches are set to the selected address.
[∗] to continue
Module Addresses
Address Module
07 1st 4229 (with zones 09-16)
08 2nd 4229 (with zones 17-24)
09
†
3rd 4229 (with zones 25-32)
10
†
4th 4229 (with zones 33-40)
11
†
5th 4229 (with zones 41-48)
12 1st 4204
13 2nd 4204
14
†
3rd 4204
15
†
4th 4204
† These addresses apply to VISTA-20PMT only.
REL POSITION (actual relay number on module)
For 4204 modules, relay numbers are 1-4. For 4229 modules, relay
numbers are 1-2.
[∗] to return to the Output Number prompt for programming the next
device
This is the actual (or physical) relay number with respect to the Relay
Module upon which it is located. For 4204 modules, relay numbers are
1-4. For 4229 modules, relay numbers are 1-2.
The system returns to the Output Number prompt for programming the
next device.
