– 23 –
AVS SYSTEM ENABLE and QUICK PROGRAMMING COMMANDS
Applies to an AVS system using an ECP connection to the control.
1. Install the AVS module according to its instructions.
2. Use one of the control’s AVS Quick Program commands as follows (see Quick Program Command Results below for
results of each command):
installer code + [#] + 0 + 3: enable AVS operation without panel sounds on the AVST speaker
installer code + [#] + 0 + 4: enable AVS operation and enable panel sounds on the AVST speaker
3. Use data field 55 Dynamic Signaling Priority to select the desired reporting paths (phone line and/or GSMV) and path for
AAV communication.
To undo the Quick Command programming if necessary, use the following commands:
installer code + [#] + 0 + 5: remove all options set by [#] + 03 quick command
installer code + [#] + 0 + 6: remove all options set by [#] + 04 quick command
Quick Program Command Results
When either the #03 or #04 Quick Program command is used, the following are automatically programmed and no longer
available for other control panel purposes.
Pre-Programmed #03 Command #04 Command
Output Function No.
(80 mode)
VISTA-15PMT series
22 (zone type 60, relay 07)
23 (zone type 61, relay 08)
24 (zone type 62, relay 08)
VISTA-20PMT series
46 (zone type 60, relay 15)
47 (zone type 61, relay 16)
48 (zone type 62, relay 16)
VISTA-15PMT series
Same as #03 plus:
17 (zone type 14, relay 05)
18 (zone type 22, relay 05)
19 (zone type 39, relay 06)
20 (zone type 33, relay 06)
21 (zone type 36, relay 06)
VISTA-20PMT series
Same as #03 plus:
41 (zone type 14, relay 13)
42 (zone type 22, relay 13)
43 (zone type 39, relay 14)
44 (zone type 33, relay 14)
45 (zone type 36, relay 14)
Output Relay No.
(79 mode)
07 (addr 08, relay pos 2)
08 (addr 08, relay pos 1)
15 (addr 11, relay pos 2)
16 (addr 11, relay pos 1)
Same as #03 plus:
05 (addr 08, relay pos 4)
06 (addr 08, relay pos 3)
Same as #03 plus:
13 (addr 11, relay pos 4)
14 (addr 11, relay pos 3)
Protection Zone
(56/58 mode)
4229 zn 24 (zt 81, addr 08) 4229 zn 48 (zt 81, addr 11) Same as #03 command Same as #03 command
Device Address address 08 (AVS module) address 11 (AVS module) Same as #03 command Same as #03 command
Data Field 91
AAV enabled AAV enabled AAV enabled AAV enabled
UPLOADING/DOWNLOADING VIA THE INTERNET
UL: Up/downloading via the Internet has not been evaluated by UL.
The control, when used with an appropriate communication device (ex. 7845i-ent, 7845i-GSM), supports upload/download
programming capability via the Internet or a Private local area network (Intranet) instead of using telephone lines. This allows
site maintenance independent of central station monitoring, and modification to sites globally via the Internet or through a
private LAN.
Refer to the instructions provided with the communication device for information regarding its installation, programming, and
registration. The System Requirements table below lists two sets of system requirements, depending upon whether you intend
to communicate over the Internet using AlarmNet Services, or whether you are communicating over a Private LAN (Intranet).
System Requirements
Internet Communication
At the Installation Site:
Appropriate Internet/Intranet Communication Module
7720P Programmer
Internet Access and Cable/DSL Modem
Cable/DSL Router (optional, if connecting more than one
device)
Control Panel
Intranet (Private LAN) Communication
At the Installation Site:
Appropriate Internet/Intranet Communication Module
7720P Programmer
Ethernet Network Connection
Control Panel
To set up the control panel, do the following:
1. Connect the communication device to the control panel’s ECP (keypad) terminals.
2. Internet Users: Connect the communication device to the Internet via a cable/DSL modem and router.
Intranet Users: Connect the communication device to the Intranet (LAN) via the appropriate Ethernet connection.
3. Enable the communication device in the control panel (using 29 Menu mode) to enable alarm reporting and module
supervision.
4. Using the communication device’s programming menus (via 29 Menu mode or 7720P programmer), program the
communication device for address 3 and program the device’s other options as required.
5. Register the communication device with AlarmNet. The communication device must be registered before downloading or
alarm reporting can take place.
To perform upload/download functions:
1. Connect the computer to the Internet and start the Compass downloading software.
2. Open the control’s account, then select the Communications function and click the Connect button.
3. At the Connect screen, check that the control’s MAC address is entered and the TCP/IP checkbox is checked.
4. Click Connect. The Internet connection to the control is made automatically via AlarmNet.
5. Once connected, use the Compass downloading software as normal to perform upload/download functions.
