– 19 –
“C”
(if zone number was selected)
ENTER ZN NO.
Enter the desired zone number, then press [∗] to continue. At the
ENTER EVENT prompt, enter the zone event that will activate
this output (0 = restore; 1 = alarm/fault/trouble).
Press [∗] to continue to the OUTPUT ACTION prompt
OUTPUT ACTION
0 = off
1 = Close for 2 seconds
2 = Close and Stay Closed
3 = Continuous Pulse 1 sec on and 1 sec off
4 = Change Device State; 5 = Duration 1 (see data field *177); 6 =
Duration 2 (see data field *177)
Press [∗] to continue.
Enter the desired device action.
ENTER OUTPUT NO.
Enter the device output number (programmed in *79 Menu Mode)
you want associated with this output.
01-16 = VISTA-20PMT output no.
01-08 = VISTA-15PMT output no.
17-18 = on-board triggers
Press [∗] to continue.
SUMMARY SCREEN
A summary screen appears showing the programmed settings.
Press [∗] to return to OUTPUT FUNCTION NUMBER prompt.
∗
∗∗
∗81 ZONE LIST MENU MODE
(press *81 while in Programming mode)
The Zone List Worksheet is on page 29.
Zone lists let you group individual zones for use with certain system actions. Using this mode, simply
select an appropriate
zone list number, then add the desired zone numbers to be included in that list.
The following table shows the available zone lists and their purposes:
List No. Used for… Notes
1, 2 general purpose (GP)
3 chime-by-zone (see field *26 to enable option)
4 cross zones (see note at right)
5 night stay zones
6
dial delay disable
7
unlimited reports
8 general purpose
9 zones that activate Pager 1
10 zones that activate Pager 2
11 zones that activate Pager 3 (VISTA-20P)
12 zones that activate Pager 4 (VISTA-20P)
• Any list may include any or all of the system's zone numbers.
• A zone list can be assigned to more than one output relay.
• Zone List 4: When creating zone list 4 for cross zoning,
include only zones assigned to zone types 3, 4, or 5. Do not
include zones that have delays (entry/exit zones, interior
w/delay) or 24-hour zones, as these zone types may produce
unpredictable operation and may not function as intended.
See field *85 for Cross Zone Timer option.
• Zone List 6: See field *50 for Dial Delay Disable option.
• Zone List 7: See field *93 for Unlimited Reports option.
ZONE LIST NO.
Enter the zone list number (01-12) to program (or 00 to exit this
mode). Press [∗] to continue.
ENTER ZN NUM.
Enter each zone number (01-64†) to add to the zone list, followed
by pressing [∗] (example, 01∗, 02∗, 03∗).
Press 00 to continue.
† VISTA-20PMT = 01-64; VISTA-15PMT = 01-06, 09-34, 49-56.
IMPORTANT: Do not include fire zones in zone lists that are
used to STOP device actions.
DEL ZN LIST?
0 = don’t delete list; current zone list remains saved
1 = delete this zone list; All zones in the zone list will be deleted.
[∗] to continue
DELETE ZONE?
0 = don’t delete zones; save the entire zone list and return to the
Zone List No. prompt
1 = go to next prompt to delete zones
[∗] to continue
ZN TO DELETE?
Enter each zone (01-64†) to be deleted from the list, following
each with [∗].
00 when done to return to the Zone List No. prompt.
† VISTA-20PMT = 01-64; VISTA-15PMT = 01-06, 09-34, 49-56.
