Moomba Mojo User Manual

41
© 2014 Skier’s Choice, Inc.
When bags begin to vent, shut o!
Do Not overll ballast bags!
Mondo
Outback V
Mobius LSV
Mojo 2.5
Boat Model
4.5 minutes
3 minutes
4.5 minutes
4.5 minutes
4.5 minutes
4.5 minutes
6 minutes
6 minutes
2014 Moomba Ballast Fill Times
Front Ballast Rear Ballast Time
oUTbaCk V ballasT Panel
The Gravity Ballast System in your boat is an electronically
controlled ballast system that can be operated from the driver’s
seat. The manual switches for this three position system
are located in the switch panel directly below the shifter
mechanism.
The Ballast System in your boat is an integrated and logically
controlled system. At the heart of the system is a series of
reversible pumps that use impellers to pump water in and out of
the ballast system. The controller for the system runs the pumps
an appropriate amount of time to ll and to empty the bags.
Filling the System-In normal operation of the system, ipping
one of the switches to “Fill” will start the system lling the
associated ballast. The pump will automatically turn o when
the appropriate amount of time to ll the system has been
reached. The light on the switch will still be luminated as it
is in the “Fill” position, but the pump will not be running. The
switch should be turned back to the “o” position when the
pump stops running.
Emptying the System-In normal operation of the system,
ipping one of the switches to “Empty” will start the system
emptying the associated ballast. The pump will automatically
turn o when the appropriate amount of time to empty the
system has been reached. The Light on the switch will still be
luminated as it is in the “Empty” position, but the pump will
not be running. The switch should be turned back to the “o”
position when the pump stops running.
Ballast Pump Impellers- The pumps that ll and drain the
ballast system use an impeller. Your Moomba ballast impeller
uses the latest polymer technology in an eort to have the
longest service life possible. The impellers are a wear item
and dierent use patterns, water types, debris, etc. can greatly
aect the service length of the impeller. As the impellers
wear, the amount of water that is pumped into and out of the
ballast system is reduced. Running the pumps without water
will greatly accelerate the wear and prolonged running of the
pumps without water will damage the impeller to the point that
they will require immediate replacement.
Note: Impellers are a wear item and not covered by warranty.
M seRIes ballasT Panel

Moomba Mojo Specifications

General

Beam	102 inches
Wakeboard Tower	Standard
Length	23 ft
Fuel Capacity	70 gallons
Engine	400 Indmar Raptor 6.2L
Ballast Capacity	4, 000 lbs
Engine Options	Indmar Raptor 6.2L 400
