330A Nēo Series
Remote Operation
Figure 4: Remote Operation
In figure 4 we have a Nēo 350P Preamplifier and 330A Amplifier connected together via their respective 12V
triggers; The 12V trigger output on the 350P is connected to the 12V trigger input on the 330A using a 1/8” mini-
jack cable. When you turn on the 350P via remote control (or its Standby button), the 330A will automatically turn
on. The same rule applies when you put the 350P into Standby mode.
12
