SS03/05/10-EC Hardware Manual
+86-400-820-9661
47.14
φ38.1
47.14 4-φ5.1
56.3
A
A1 FLAT
B
B1
1.6
L
7
30033
73.6
Model A A1 B B1 L
AM23SS2DGA-N φ8 7.5 24 20 77.5
AM23SS2DGB-N φ6.35 5.85 20 15 77.5
AM23SS3DGA-N φ8 7.5 24 20 99.5
AM23SS3DGB-N φ6.35 5.85 20 15 99.5
AM23SS4DGA-N φ8 7.5 24 20 102.5
4-φ4.547.14
47.14
φ38.1
60
B1
B
A1 FLAT
A
1.5
8
110
77.4
33
300
Model A A1 B B1
AM24SS3DGA-N φ10 9.5 24 20
AM24SS3DGB-N φ8 7.5 20.6 15
AM23SS-N
unit: mm
AM24SS-N
unit: mm
