-34-
Installing the new brake caliper
1. First, inspect the brake assembly for grooves, aking, cracks, heat
checking, thickness variation, insufcient rotor thickness, and look to
see that the mounting hardware is straight. Replace any component as
needed (or desired) per manufacturer recommendations.
2. Install the new caliper assembly. Make sure that the bleed screw points
up.
3. Remount the caliper assembly onto the caliper attaching bracket.
Ensure that there is thread locking compound on the threads of the new
mounting bolts. Torque mounting bolts to 40-50 Ft. Lbs.
Note: Use two lug nuts to secure rotor against the hub face when
reassembling the caliper. After the caliper is assembled remove the lug
nuts.
4. Reconnect the hose to the elbow adapter on the back of the caliper and
torque to 10-12 Ft. Lbs.
5. Reconnect the brake actuation system. Refer to your actuation systems
Operation Maintenance Service Manual for proper operation.
6. Bleed and ush brake system per your actuation systems Operation
Maintenance Service Manual.
7. Remount the wheel. Refer to your Operation Maintenance Service
Manual for proper wheel nut torque procedures.
Instructions for Brake Rotor Kit
3.5K Hydraulic Disc Brakes
Notice to Buyer
It is recommended that all brakes be replaced at the same time to ensure
balanced braking performance.
Remove the old brake rotor
1. Jack up trailer and secure on adequate capacity jack stands. Follow
trailer manufacturers recommendations for lifting and supporting the
unit.
Braking Systems - Hydraulic
