-78-
Replacement Parts/Kits
Electric Brake Magnets
Brake Size
Magnet Kit Number
(one magnet per kit)
Wire
Color
Nut Torque
(Ft. Lbs.)
Brake Mounting
7" x 1 1/4" K71-057-00 White 45-70
10" x 1 1/2" K71-104-00 Green 45-70
10" x 2 1/4" K71-104-00 Green 45-70
10" x 2 1/4" K71-125-00 (4.4K) Black 45-70
12" x 2" K71-105-00 White 25-50
12" x 2" K71-125-00 (7K) Black 25-50
12 1/4" x 2 1/2" K71-378-00 (7.2K) Red/Black 55-80
12 1/4" x 3 3/8" K71-378-00 Red/Black 55-80
Seal Replacement Reference
Brake Size Hub Size Standard
Seal Part No.
E-Z Lube
®
Oil
7" x 1 1/4" 4 or 5 Bolt K71-301-00 K71-301-00 N/A
10" x 1 1/2" 5 Bolt K71-302-00 K71-302-00 N/A
10" x 2 1/4" 4, 5 or 6 Bolt K71-303-00 K71-303-00 N/A
12" x 2"** 5 Bolt Demount;
6 or 8 Bolt
K71-305-00 K71-305-00 K71-386-00
12 1/4" x 2 1/2" 8 Bolt K71-305-00 K71-305-00 K71-386-00
12 1/4" x 3 3/8" 8 Bolt K71-305-00 K71-305-00 K71-386-00
** 2.12" diameter seal journal prior to 10/97
2.25" diameter seal journal after 10/97
Replacement Parts/Kits
