-39-
4. Ensure spindle nut retainer is in place. Install new grease or oil cap with
rubber plug, and torque as shown on cap.
5. Remount the caliper assembly onto the caliper attaching bracket. It
may be necessary to push the piston into the calipers to obtain enough
clearance. Torque mounting bolts to 25-35 Ft. Lbs.
6. For brakes produced after April 2008, locate the tube clamp attached
to the crossover brake line and attach to the caliper mounting bracket.
Using the1/4-20 bolt, torque to 85-100 In. Lbs.
7. Spin the hub/rotor to ensure that there is enough clearance between the
rotor and the crossover brake line.
8. Reconnect the brake actuation system. Refer to your Operation
Maintenance Service Manual for proper operation.
9. Remount the wheel. Refer to your Operation Maintenance Service
Manual for proper wheel nut torque procedures.
10. Spin the wheel to ensure that there is enough clearance between the
wheel and crossover brake line or caliper.
Instructions for Brake Pad Kit
6K, 7K or 8K Hydraulic Disc Brakes
Notice to Buyer
It is recommended that all brakes be replaced at the same time to ensure
balanced braking performance.
Remove the old brake pads
1. Jack up trailer and secure on adequate capacity jack stands. Follow
trailer manufacturers recommendations for lifting and supporting the
unit.
Braking Systems - Hydraulic
