LOR Digital Controller (LDC) October 2020
Specifications
Table 2: General Specifications
Weight 8 oz
Operating Temperature -4–158°F (-20–70°C)
Ingress Protection IP 67
Voltage Supply 9–32 VDC
Current Consumption Outputs OFF - 50mA (12 VDC) 30mA (24 VDC)
CAN Protocol J1939
Table 3: User Interface
Display 400 × 240 pixel 2.83″ Transflective Sunlight Readable
Backlight Yes
LEDs Amber–Caution/Warning (J1939)
Blue–Output #2 Feed Reverse
Green–Output #1 Feed Forward
Red–Shutdown (J1939)
Keypad 8 or 4 Position Tactile. IP 67 Sealed, Rated to 100,000 Cycles
Connection 2 × 12 pin Deutsch connectors
Table 4: Input Specifications
Voltage Inputs
Number Up to 16 (7 × Wide Band; 9 × Narrow Band)
Signal Range Wide: 0–27 VDC
Narrow: 0–10VDC
Max Voltage 32 VDC
Resolution Wide: 6.7 mV/bit
Narrow: 2.44 mV/bit
Frequency Inputs
Number 2
Frequency Range 2–20,000 Hz
LOR Manufacturing Company, Inc. 15
