October 2020 LOR Digital Controller (LDC)
• +5 VREF (mV)
• RPM Down (mV)
• RPM Up (mV)
• Drum Speed (RPM)
Outputs
This screen shows the status of the LDC’s Outputs. The following parameters are displayed on this screen.
• Feed FWD (mV)
• Feed REV (mV)
• Purge Request (mV)
• Purge Valve (mV)
Adjust Sub-Menu
This menu allows users to make adjustments to various parameters of the system.
• OEM Settings
• CAN Settings
• Autofeed Settings
Note
OEM and CAN settings are set from the factory and protected by a 4 digit PIN Code.
Autofeed Settings
This screen allows users to make adjustments to the following Autofeed settings:
• High RPM–Set below maximum RPM. This is the speed at which Feed system resumes operation.
• Low RPM–Set below High RPM. This is the speed at which the Feed system stops and reverses
2
• Reverse Time in milliseconds
Note
These settings only apply to the ”Customer” Autofeed mode. All other modes are set at the
factory.
2
If equipped.
30 LOR Manufacturing Company, Inc.
