October 2020 LOR Digital Controller (LDC)
Table 4: Input Specifications
Minimum Signal Voltage 2 VAC
Resistive Inputs
Number 1
Signal Range 0–1,000Ω
Table 5: Output Specifications
PWM Outputs
Number Up to 6
Type High Side Switching (Hydraulic Solenoids, Horns, Lights, Relays, etc.)
Max Load 3.5 A Continuous
PWM Frequency 31–500Hz
Duty Cycle Resolution 0.10%
Protection Overload Shutdown
Open Load Detection
Relay Output
Number 1
Type Dry Contact Normally Open
Max Load 500 mA
Note
Inputs and Outputs may share pin assignments.
16 LOR Manufacturing Company, Inc.
