-63-
5. Install “internal” snap ring into hub.
6. Clean and inspect spindle shaft. Apply a light coating of anti-seize
lubricant to the spindle shaft prior to assembling drum.
7. Install drum assembly onto spindle (Do Not Force).
8. Install steel washer onto spindle end.
9. Start self-locking nut onto spindle thread by hand. Complete installation
using a 1 7/16" 6 or 12 point socket and torque wrench. Nut should
be torqued to 145-155 Ft. Lbs. (this torque will set the internal bearing
adjustment, no other adjustments are to be made).
10. Install “torque instruction” washer onto end of spindle.
11. Install “external” snap ring onto end of spindle to retain washer.
12. Inspect assembly for excessive end play, noise, and rotation restriction
prior to mounting nal wheel end hardware.
Hubs/Drums/Bearings
