10
Room Thermostat
This menu is used for setting the room thermostats used by the stove.
• To select the item in the menu use the buttons. To
confirm press SET. To exit press ESC.
Radio Room Thermostat: This menu allows to set the temperature on
the Remote control Thermostat.
Remote Room Thermostat (C Models): Allows to set the temperature
on the Remote Room Thermostat.
Hot Air (Relax models)
This menu allows the adjustment of the heating fan. It is
possible to set one of the following: 1,2,3,4,5, AUTO. The
power level of the heating fan operates independently
from the combustion power level settings.
Chrono
This menu is used for setting the on/off switching time
frames.
• To select the item in the menu use the
buttons. To
confirm press SET. To exit press ESC.
Modality: To switch the stove on/off, it is necessary to select Modality
after the on/off time frames have been programmed.
• To select the item in the menu use the buttons. To
confirm press SET. To exit press ESC.
Chrono Program: Select a desired program for setting (after
programming the time frames, to enable the on/off switching of the stove,
it is necessary to select the desired mode from the Modality submenu:
Chrono
Eco Clima
Calibratiom
Time and Date
Load
Room Thermost
Rem.1 Room The
Radio Room Ther
Room Thermost
Eco Clima
Calibration
Time and Date
Load
Chrono
Chrono Program
Modality
Modality
Disabled
Weekly
Week-End
Daily
Chrono Program
Modality
Run Mode
After the ignition, the system goes into Run Mode. During this phase the
heating fan is activated and the system operates on the set combustion
power level.
Modulation
During the Run mode, the aim of the stove is to reach the set room
temperature, when this goal is achieved, the system goes into
Modulation where the fuel consumption is minimal and the fan will run at
the lowest speed power setting.
Combustion power setting
It is possible to modify the combustion power level at any time, but the
change is effective only in Run Mode. The power level ranges from 1 to
5. Increasing the power equals to a high pellet consumption and the
heating fan turning at high speeds.
Automatic combustion (Pot: Auto)
It is possible to select the automatic combustion setting (Pot: Auto) in the
same way the combustion power level is selected. By selecting Pot:
Auto, the system automatically adjusts the combustion power and
adjusts it to the room set temperature on the display radio. The higher
the difference between the actual room temperature read and the one
set on the display radio, the higher the combustion power level the stove
will automatically set and vice versa.
Eco Clima
When the room temperature is reached, the control unit reduces the
pellet consumption to a minimum by activating the Modulation phase,
then the system will verify if this temperature is maintained for a set
period of time and if this occurs, the stove will automatically switch to
Standby (the stove turns off).
By using this mode it is necessary to make sure that after each
automatic turn off, the burner must be cleaned in order to
guarantee a correct automatic ignition.
Note: The stove operating on the Eco Clima mode, can turn itself on and
off several times during a day. This though can consume the ignition
resistance for the automatic ignition.
Note: Turn off the stove in case of damage or malfunction.
THE MENUS
To enter the remote control Menu, press the SET button. A list of
Submenus will appear. When memorizing a new set value, it is also
transmitted towards the stove.
Order User menu
1 Room Thermostat
2 Hot Air (Relax Models)
3 Chrono
4 Eco Clima
5 Calibration
6 Time and Date
7 Load
8 Monitor
10 Settings
11 System Menu
9 Language
