11
• To select the item in the menu use the buttons. To
confirm press SET. To exit press ESC.
Daily
Select a desired day of the week and program the on/off switching time
frames. There are 3 on/off switching time frame phases for each day.
Weekly
It modifies directly the on/off switching time frames and there are 3
phases throughout the week.
Week-End
Selecting between “Monday-Friday” and “Saturday-Sunday” periods.
There are 3 phases for “Monday-Friday” and 3 phases for “Saturday-
Sunday”.
Time frame enable
Once the desired program has been selected:
• Select the time frame with that has to be set and enter
edit mode (the time starts flashing) by pressing SET.
• Modify the time with and save the setting by
pressing SET.
• Enable the time frame appears or disable appears by
pressing the button
• Press ESC to exit.
Programming through the Midnight
Set the switch OFF time at 23:59 for a week day time frame. Then set
the switch ON time for the following week day at 00:00.
Program
Weekly
Week-End
Daily
Tuesday
Wednesday
Thursday
Friday
Daily Monday
Daily
Monday
ON OFF
09:30 11:15
00:00 00:00
00:00 00:00
Program
Daily
Week-End
Weekly
Mon-Sun
ON OFF
09:30 11:15
00:00 00:00
00:00 00:00
Weekly
Program
Daily
Weekly
Week-End
Sat-Sun
Week-End
Mon-Fri
Week-End
Mon-Fri
ON OFF
09:30 11:15
00:00 00:00
00:00 00:00
The three different programs are memorized separately. eg: if the daily
program is modified, the other modalities do not change.
Eco Clima
If the function is disabled, the stove goes into Modulation once the Room
Thermostat set temperature is reached. If the function is active, once the
Room Thermostat set temperature is reached, the stove goes into
Modulation then into Standby.
• To select the item in the menu use the buttons. To
confirm press SET. To exit press ESC.
Calibration (models with FCS)
Menu for adjusting the automatic combustion correction range.
• To select the item in the menu use the buttons. To
confirm press SET. To exit press ESC.
MCS Calibration: Menu for adjusting the automatic combustion
correction range. There are 10 levels, 5 to increase and 5 to decrease,
the 0 level is the manufacturers default setting.
Calibration (models without FCS)
Menu for setting manually the combustion parameters.
• To select the item in the menu use the buttons. To
confirm press SET. To exit press ESC.
Auger Calibration: Menu for setting the operating time of the auger.
There are 10 levels, 5 to increase and 5 to decrease, the 0 level is the
manufacturers default setting.
Room Thermost
Chrono
Calibration
Time and Date
Load
Eco Clima
Eco Clima
Off
On
Room Thermost
Chrono
Eco Clima
Time and Date
Load
Calibration
MCS Calibration
Room Thermost
Chrono
Eco Clima
Time and Date
Load
Calibration
Fan Calibration
Auger Calibration
