Moretti Design ARIA - Combustion and Calibration; Combustion Calibration

5
Warning:
The chimney must be constructed according to regulation
standards.
For an external installation, use an insulated chimney flue that can
be inspected on the curves
Do not use synthetic materials or aluminium.
Use only stainless steel tubes.
All sections of the fume exhaust must be accessible for inspections
and internal cleaning.
The minimum draft at nominal power must be 10 Pa, the minimum
draft at reduced power must be 5 Pa.
The outdoor section of the barrel must be insulated.
Failure to comply with the above will void the warranty.
Operating conditions
The stove has been designed to be used in ordinary environments,
where there is no danger of possible fire outbreaks or explosions.
Disposal of the combustion waste, must be carried out in accordance
with local regulations. While using the stove, the settings can not be
changed or the protective casings removed. The control devices must be
adjusted by Moretti Design qualified personnel. The maintenance of the
product must be carried out by companies specialized in the
maintenance of heating appliances and authorized by Moretti Design,
which will submit it to all the checks ups required by the local regulations.
Use only 6mm diameter and 30mm average length wooden pellets.
Caution: A stove that has been modified or altered, must be
subjected to further verifications in compliance with the law. The
improper connection of the stove to the flue and the non-
compliance of regulations for the installation of air vents can cause
serious danger to people and will void the warranty.
PROTECTION
CAP
INSULATED
CHIMNEY
FLUE
CHIMNEY
FLUE
“T” WITH
INSPECTION
CAP
INTERNAL CHIMNEY FLUE
CORRECT
INSTALLATION
CHIMNEY FLUE THROUGH OUTSIDE WALL
CORRECT
INSTALLATION
PROTECTION
CAP
INSULATED
CHIMNEY
FLUE
INSULATED
“T” WITH
INSPECTION
CAP
CHIMNEY
FLUE
“T” WITH
INSPECTION CAP
“T” WITH
INSPECTION
CAP
EXTERNAL FREE CHIMNEY FLUE
IMPROPER
INSTALLATION
