Morgana DigiFold Pro - Replacing Blade Sets

Page38
FOLDING
1.Beforeremovingthebladeassembly,ensurethatthelowerblade/anvilisat‘TopDead
Centre’,seepage37.
2.Liftthetopcover.
3.Usinga5mmallenkey,removethetwosocketheadscrews,oneeachendoftheBlade
Set,asshowninFIG32.1below.
4.RemovetheSheetGuideAssembly,bypullingupwardsonthetwoflanges,oneeach
end,asshowninFIG32.2andFIG32.3below.
5.TheBladeSetcannowberemovedfromthemachineusingtheBladeExtractorTools
showninFIG32.4below.
ReplacingBladeSets
FIG32.1
FIG32.2 FIG32.3
Flange
SheetGuideAssembly
FIG32.4
BladeExtractorTools
