Page39SYSTEM
ReplacingBladeSets
6.InserttheBladeExtractorTools,oneateachendoftheBladeSet,asshownin
FIG33.1below.
7.LevertheBladeAssemblyinthedirectionshowninFIG33.2tounclipandreleasethe
BladeSet.
FIG33.1
FIG33.2
NoteThePositionofThe
BladeExtractorTool
UnderTheLipofThe
BladeAdjusterAssembly
