Morgana DigiFold Pro - Page 40

FOLDING
FIG34.2
Page40
ReplacingBladeSets
8.Slidethebladeassemblyoutofthecreasingunitandlayitonaflatsurface.
9.Slidethebladeadjustmentcamsandthebladeadjustmentassembliesawayfromthe
dowelslocatedintheendsoftheblades/anvilsasshowninFIG34.1below.
11.SlidethenewbladesetintotheslotsofthecreasingunitasshowninFIG.34.2.
12.Rotatethebladeadjustmentcamsuntiltheyarejusttight,andthenbackoffslightly.
Resetbladeto‘TopDeadCentre’andmakefinaladjustments.
10.Slidethebladeadjustmentassembliesandthebladeadjustmentcamsontothe
dowelsofthenewbladeset.
FIG34.1
