功能选择键和显示屏幕
FUNCTION SELECTION KEYS AND DISPLAY SCREENS
208
使用功能选择键
s
( 设定 ) 可进入的屏幕菜单，显示在屏幕上。 The menu of the screens accessible using the function
selection key
s
(SETTING) is displayed on this screen.
为了进入所需的屏幕，输入所需屏幕的菜单编号并按下
[
(Enter) 键 /
\
( 输入 ) 键。也可以按下相应的软键改变显示屏
幕。
To access the required screen, input the menu number of the
required screen and press the
[
(Enter) key/
\
(INPUT) key.
It is also possible to change the display screen by pressing the
corresponding soft-keys.
‘ 此机床的面板设定 ’屏幕 ‘ MACHINE OPERATION PANEL SETTING ’ Screen
通过按下
[
[ONE TOUCH] ( 单触归零 ) 按钮，此屏幕用于设
置轴返回至零点的顺序，并为 [ 快进倍率 ] 开关设定值 (%)。
This screen is used to set the order in which axes return to the
zero points by pressing
[
[ONE TOUCH] (One-Touch Zero
Return) button and to set values (%) for the [RAPID
OVERRIDE] (Rapid Traverse Rate Override) switch.
< 设置各轴归零的顺序 > <Setting the order of zero return of each axis>
1) 使用光标在‘ 操作面板设置改变 ’中选择‘ 有效 ’。 1) Select ‘ VALID ’ in ‘ OPERATION PANEL SETTING
CHANGE ’ using the cursor.
2) 将光标移动到 X、Y、Z、C、B 栏，然后根据各轴归零顺序
输入“1”、“2”、“3”、“4”或“5”。为不应返回零点的轴设
置“0”。
2) Move the cursor to the X, Y, Z, C, B column, then input “ 1 ”,
“2”, “3”, “4” or “5” according to the order of the zero
return for each axis. Set “ 0 ” for the axis that should not be
returned to its zero point.
< 更改快速进给倍率的设置值 (%)> <Changing the setting values (%) of the rapid traverse
rate>
1) 使用光标在‘ 操作面板设置改变 ’中选择‘ 有效 ’。 1) Select ‘ VALID ’ in ‘ OPERATION PANEL SETTING
CHANGE ’ using the cursor.
2) 将光标移动到要改变的“ 快进倍率 ”，然后输入 1 到 50(%)
范围内的任意值。屏幕上的‘ 快速修调 1’、“2”和“3”分别对
应机床操作面板上的 [ 快进倍率 ] 开关 1 、2 和 3 。
2) M
ove the cursor to the “ RAPID OVERRIDE ” to be
changed, and then input any value ranging from 1 to
50(%). ‘ RAPID OVERRIDE 1 ’, “ 2 ” and “ 3 ” on the screen
correspond to the [RAPID OVERRIDE] (Rapid Traverse
Rate Override) switch 1 , 2 and 3 on the machine
operation panel respectively.
‘ 操作面板 ’屏幕 ‘ OPERATION PANEL’ Screen
此屏幕用于设置下列功能。将光标移动到所需的项目，并选择
所需状态（有效 / 无效）。
This screen is used to make settings for the following functions.
Move the cursor to the required item and select the required
status (Valid/Invalid).
<Z 轴忽略功能 > <Z-Axis Neglect Function>
忽略 Z 轴手动操作和已编程的 Z 轴运动指令且 Z 轴不再进给。
根据轴运动指令的执行，仅更新位置数据。
Manual Z-axis movement operation and programmed Z-axis
movement commands are ignored and the Z-axis is not fed.
Only position data is updated according to the execution of an
axis movement command.
除了 Z 轴指令外的轴运动指令都按编程执行。 The axis movement commands of other than Z-axis command
are all executed as programmed.
此功能用于在无 Z 轴运动操作时检查程序。 This function is used to check a program without Z-axis
movement operation.
2 注意 2 NOTE
使用 Z 轴忽略功能检查程序时，提前将 Z 轴归零。除 Z 轴外的其余轴
都按编程运动。
When checking the program using the Z-axis neglect function, return
the Z-axis to the zero point in advance. The axes other than the Z-axis
are moved as programmed.
功能选择键
s
( 设定 ) D [ 设定 ] D [>] D [ 面板设定 ]
Function selection key
s
(SETTING) D [SET] D [>] D
[PANEL SETTING]
1
2
3
1
2
3
功能选择键
s
( 设定 ) D [ 操作面板 ]
Function selection key
s
(SETTING) D [OPE. PANEL]
