2-25
2.17 UNDERCOVER
When changing the coolant, do as follows to remove the undercover.
1. Set a garage jack under the center of undercover (1).
Set a wooden block between the jack and the undercover to prevent
damage to the undercover.
2. Remove 3 mounting bolts (2), then lower the jack and open undercover (1).
3. After completion of inspection and maintenance, put undercover (1) on the
jack, set it at the mounting position under the machine, then tighten
mounting bolts (2).
Applicable to Cab Specifications
Applicable to Canopy Specifications
