2-37
[3] SWITCHING BETWEEN HIGH AND LOW SPEED RANGES
The travel speed range is changed by operating the Hi-Lo speed range
selector switch.
• When the switch is pressed, the mechanism inside the travel motor is
switched and the machine changes to the high speed range.
At the same time, the high-speed lamp on the instrument panel lights up to
show that the machine is traveling in the high speed range.
• If the switch is pressed again, the mechanism inside the travel motor returns
to its original position, and the machine travels in the low speed range.
At the same time, the high-speed lamp on the instrument panel goes out to
show that the machine is traveling in the low speed range.
To Next Page
