[2] PREPARATIONS FOR MOVING FAILED MACHINE
When moving a machine which has had its parking brake released manually, the distance of movement should
be only the few meters needed to move it to a safe place.
Moving the machine a long distance will cause failure of the HST.
When moving a failed machine, carry out the following preparatory work.
Go under the machine and turn adjustment screw (7) of multi-function valves
(6) (4 places) at the bottom of main pump (5) approx. 3.5 turns to the left.
The oil inside the HST circuit will flow freely.
When starting normal operations again after completion of repair of the
machine, always turn adjustment screw (7) of multi-function valve (6) approx.
3.5 turns to the right to return it to the original position.
If the multi-function valve is not returned to the original condition, the machine
will not move.
