4. Description
26
1 - Frame
2 - Control panel
3 - Fuel tank cap
4 - Engine
5 - Oil drain plug
6- Oilllercap/Oilleveldipstick
7- Mu󰀪er
8- Engineairlter
9 - Engine switch
10 - Starter handle
11 - Vibration dampers
12 - Welding level reactor
13 - Choke control
14 - Fuel valve
15 - Alternator
16 - AC inverter
17 - Welding current control board
18 - Hall sensor
19 - Chopper bridge
4.2 Control panel components
1
2
3
4
5
6
7
D5260910
1 - Welding current adjustment
2 - Welding socket (+)
3 - Welding socket (-)
4 - Auxiliary generation overload LED
5 - Auxiliary AC power outlet socket
6 - PE ground terminal
7 - Hour meter
