Mosa Magic Weld 200 - Pre-Start Checks; Engine Starting and Stopping

6. Operation
30
6.2 Checks before start-up
1 - Check the oil and fuel levels. For the details, see “7. Maintenance”.
2 - Check that there are no oil and fuel leaks.
3 - Checkthatthereisnoammableordirtymaterialaroundthemu󰀪er.
4 - Check that there are no unauthorized persons in the area adjacent to the machine.
6.3 Starting and stopping the engine
WARNING
• Do not alter the primary adjustment conditions and do not tamper with sealed parts.
6.3.1 Starting the engine
1 - Turnthefuelvalve(1)totheONposition.
1
D5261030
ON
2 - Turn choke control (2) to the closed position (C).
WARNING
• Do not leave the choke control closed when the
engine is hot or the air temperature is high.
2
D5261040
C
3 - Turntheengineswitch(3)totheONposition.
O
I
3
D5261050
OFF
ON
