* 157.075 161.675
* 157.125 161.725
* 157.175 161.775
84 157.225 161.825
85 157.275 161.875
86 157.325 161.925
87 157.375 161.975
88 157.425 162.025
NOTE:
* Simplex channels 3, 21, 23, 61, 64, 81, 82, and 83
cannot be lawfully used by the general public in US
waters.
** Low power (1 W) only.
*** Guard band.
NOTE:
A – in the Receive column indicates that the
channel is transmit only.
Declaration of Compliance for the
Use of Distress and Safety
Frequencies
The radio equipment does not employ a modulation other
than the internationally adopted modulation for maritime
use when it operates on the distress and safety frequencies
specified in RSS-182 Section 7.3.
Technical Parameters for Interfacing
External Data Sources
RS232 USB SB9600
Input Volt-
age (Volts
Peak-to-
peak)
18V 3.6V 5V
Max Data
Rate
115 Kbps 12 Mbps 9.6 Kbps
Impe-
dance
5000 Ohm 90 Ohm 120 Ohm
