7 Side Button 1
1
8 Side Button 2
1
9 Home Button
10 4-Way Navigation Button
11 Keypad
12 Data Feature Button
13 Menu Select Buttons
14 Main Display
15 Speaker
16 Bluetooth Pairing Location Indicator
17 Top (Orange) Button
1
18 Antenna
19 Accessory Connector
20 Battery Latch
21 Battery
Programmable Features
Any reference in this manual to controls that are
preprogrammed means that a qualified radio technician
must use the radio programming software to assign a
feature to a control.
Your dealer can program the programmable buttons as
shortcuts to radio functions or preset channels/groups
depending on the duration of a button press:
Press
Pressing and releasing rapidly.
Long press
Pressing and holding for the preprogrammed duration
(between 0.25 seconds and 3.75 seconds).
Hold down
Keeping the button pressed.
Assignable Radio Functions
Bluetooth On/Off
Allows you to turn on/off the Bluetooth.
Bluetooth Configuration
Allows you to access to the Bluetooth menu.
English
