Your radio is preprogrammed to reset to medium volume

rate, which is Level 12, by default whenever the radio

powers up.

1 To increase the volume, rotate the On/Off/Volume

Control Knob clockwise.

To decrease the volume, rotate this knob

counterclockwise.

The display shows volume bars and volume level when you

change the volume.
