1 Antenna
2 Top (Orange) Button
1
3 Accessory Connector
4 16–Position Select Knob
1
5 On/Off/Volume Control Knob
6 3–Position A/B/C Switch
1
7 Belt Clip
8 Battery Latch
9 LED
10 2–Position Concentric Switch
1
11 Top Side (Select) Button
1
12 Push-to-Talk (PTT) Button
13 Side Button 1
1
14 Side Button 2
1
15 Top Display
16 Microphone
17 Main Speaker
18 Bluetooth Pairing Location Indicator
19 Battery
1
These radio controls/buttons are programmable.
