9.0 Service Aids
Table 2-1 lists the service aids recommended for working on the radio. While all of these items are
available from Motorola, most are standard workshop equipment items, and any equivalent item
capable of the same performance may be substituted for the item listed.
Table 2-1 Service Aids
Motorola Part
No.
Description Application
RLN4460 Portable Test Set Enables connection to the audio/accessory jack.
Allows switching for radio testing.
RLN4510 Battery Interface Regulates DC current and voltage between radio and
power supply.
PMKN4004 Programming Test Cable Connects radio to RIB (RLN4008).
PMKN4003 Radio to Radio Cloning Cable Allows
a radio to be duplicated from a master radio by
transferring programmed data from the master radio to
the other.
RLN4008 Radio Interface Box Enables communications between the radio and the
computer’s serial communications adapter.
5886564Z01 RF BNC Adaptor Adapts radio’s antenna port to BNC cabling of test
equipment.
0180305K08 Shop Battery Eliminator Interconnects radio to power supply.
EPN4040_ Wall-Mounted Power Supply (UK) Used to supply power to the RIB
EPN4041_ Wall-Mounted Power Supply
(220VAC)
Used to supply power to the RIB
HSN9412 Wall-Mounted Power Supply
(120VAC)
Used to supply power to the RIB
3080369B71 or
3080369B72
Computer Interface Cable Use B72 for the IBM PC AT or newer (9-pin serial port).
Use B71 for older models (25-pin serial port). Connects
the computer’s serial communications adapter to the
RIB (RLN4008).
HKN9216 IBM Computer Interface Cable Connection from computer to RIB.
6680702Z01 Knob Remover/Chassis Opener Used to remove the front cover assembly.
RSX4043A TORX screwdriver Tighten and remove chassis screws
6680387A70 T6 TORX bit Removable TORX screwdriver bit
WADN4055A Portable Soldering Station Digitally controlled soldering iron
6604008K01 0.4mm replacement tip For WADN4055A Soldering iron
6604008K02 0.8mm replacement tip For WADN4055A Soldering iron
0180386A82 Anti-static Grounding Kit Used for all radio assembly/disassembly procedures
6684253C72 Straight Prober
6680384A98 Brush
1010041A86 Solder (RMA type) 63/37, 0.5mm diameter, 2.2kg (1lb) spool.
