Motorola EP450 Service Manual

HKLN4216A November 24, 2003
Test Equipment, Service Aids, and Service Tools: Service Aids 1-3
RLN4062 Hot air workstation, 120 V Tool for hot air soldering/desoldering of surface
mounted integrated circuits
0180386A78 Illuminated magnifying glass with
lens attachment
Illumination and magnification of components
0180302E51 Master lens system
0180386A82 Anti-static grounding kit Used during all radio assembly and disassembly pro-
cedures
6684253C72 Straight prober
6680384A98 Brush
1010041A86 Solder (RMA type), 63/67,
0.5mm diameter, 1 lb. spool
0180303E45 SMD tool kit (included with
R1319A)
R1319 ChipMaster (110 V) Surface mount removal and assembly of surface
mounted integrated circuits and/or rework station
shields. Includes 5 nozzles.
R1321 ChipMaster (220 V)
ChipMaster Nozzles:
6680332E83 PLCC-28* nozzle
Soldering and Un-soldering IC’s
6680332E82 PLCC-44* nozzle
6680332E94 PLCC-52 nozzle
6680332E96 PLCC-84 nozzle
6680334E67 QFP-160 nozzle
6680333E46 SOL-18 nozzle
6680332E84 SOIC-20 nozzle
6680332E87 SOL-20J nozzle
6680333E45 SOL-24 nozzle
6680333E55 TSOP-64 nozzle
* Included with ChipMaster packages
Table 1-3. Recommended Service Tools (Continued)
Motorola Part
No.
Description Application

Motorola EP450 Specifications

General

Channel Capacity	16 channels
Operating Temperature	-30°C to +60°C
IP Rating	IP54
Frequency Range	VHF: 136-174 MHz, UHF: 403-470 MHz
Weight	Approximately 350g (with standard battery)
