Motorola EP450 Service Manual

VHF 146-174 MHz PCB 8486342Z13-C Schematic Diagrams, Overlays, and Parts Lists 6-19
HKLN4216A November 24, 2003
VHF (146-174 MHz) Radio Parts List
Circuit
Ref
Motorola
Part No.
Description
C1 2109445U41 CAP, 22pF
C2 2109445U46 CAP, 36pF
C3 2109445U49 CAP, 47pF
C4 2109445U37 CAP, 15pF
C5 2109445U14 CAP, 3.0pF
C6 2109445U37 CAP, 15pF
C7 2109445U45 CAP, 33pF
C8 2109445U44 CAP, 30pF
C9 Not_Placed CAP, 4.7pF
C20 2113743L17 CAP, 1000pF
C22 2113743L17 CAP, 1000pF
C23 2113743L17 CAP, 1000pF
C24 Not_Placed CAP, 6.2pF
C25 2113743L17 CAP, 1000pF
C26 2113743L17 CAP, 1000pF
C29 2109445U48 CAP, 43pF
C30 2109445U42 CAP, 24pF
C31 2109445U44 CAP, 30pF
C32 2109445U51 CAP, 56pF
C33 2109445U42 CAP, 24pF
C34 2109445U51 CAP, 56pF
C35 2109445U43 CAP, 27pF
C36 2109445U42 CAP, 24pF
C40 2109445U40 CAP, 20pF
C41 2109445U37 CAP, 15pF
C42 2109445U46 CAP, 36pF
C43 2109445U37 CAP, 15pF
C44 2109445U40 CAP, 20pF
C51 2113743N48 CAP, 82pF
C52 2113743N28 CAP, 12pF
C53 2109445U26 CAP, 9.1pF
C55 2113743M24 CAP, 0.1uF
C56 2113743E20 CAP, 0.1uF
C57 2113743M24 CAP, 0.1uF
C58 2113743N16 CAP, 3.9pF
C59 2113743N12 CAP, 2.7pF
C60 2113743M24 CAP, 0.1uF
C61 2113743N46 CAP, 68pF
C62 2113743M24 CAP, 0.1uF
C63 2113743M24 CAP, 0.1uF
C64 2113743M24 CAP, 0.1uF
C65 2113743M24 CAP, 0.1uF
C66 2113743M24 CAP, 0.1uF
C67 2113743M24 CAP, 0.1uF
C68 2113743M24 CAP, 0.1uF
C69 2113743M24 CAP, 0.1uF
C70 2113743N53 CAP, 130pF
C71 2113743E20 CAP, 0.1uF
C72 2113743M24 CAP, 0.1uF
C73 2113743L33 CAP, 4700pF
C74 2113743N42 CAP, 47pF
C80 2109445U41 CAP, 22pF
C81 2109445U45 CAP, 33pF
C82 2109445U41 CAP, 22pF
C90 2113743M24 CAP, 0.1uF
C91 2311049A57 CAPP, 10uF
C92 2113743E20 CAP, 0.1uF
C93 Not_Placed CAP, 3.6pF
C99 2113743M24 CAP, 0.1uF
C100 2113743L21 CAP, 1500pF
C101 2113743L21 CAP, 1500pF
C102 2113743M24 CAP, 0.1uF
C103 2113743L21 CAP, 1500pF
C104 Not_Placed CAP, 27pF
C105 Not_Placed CAP, 10pF
C106 2113743L21 CAP, 1500pF
C107 2113743N26 CAP, 10pF
C108 2113743M24 CAP, 0.1uF
C109 2113743M24 CAP, 0.1uF
C110 2113743M24 CAP, 0.1uF
C111 Not_Placed CAP, 1500pF
C112 2113743L21 CAP, 1500pF
C113 2113743L21 CAP, 1500pF
C114 2113743L21 CAP, 1500pF
C115 2311049A07 CAPP, 1uF
C116 2113743M24 CAP, 0.1uF
C117 2113741F25 CAP, 1000pF
C120 2113743L21 CAP, 1500pF
C121 2113743L21 CAP, 1500pF
C122 2113740F31 CAP, 15pF
C123 2113740F31 CAP, 15pF
C124 2113743L21 CAP, 1500pF
C130 2113740F29 CAP, 12pF
C131 2113740F15 CAP, 3.3pF
C132 2113740F37 CAP, 27pF
C133 2113740F15 CAP, 3.3pF
C134 2113740F37 CAP, 27pF
C135 2113740F17 CAP, 3.9pF
C136 2113740F30 CAP, 13pF
C137 2113740F58 CAP, 200pF
C140 2113740F30 CAP, 13pF
C141 2113740F33 CAP, 18pF
C150 2113743L21 CAP, 1500pF
C151 2113743L21 CAP, 1500pF
C152 2113743L21 CAP, 1500pF
C153 2113743K18 CAP, 0.47uF
C154 2113743L21 CAP, 1500pF
C155 2113743E20 CAP, 0.1uF
C156 2113743L41 CAP, .01uF
C157 2113743M24 CAP, 0.1uF
C158 2113743L21 CAP, 1500pF
Circuit
Ref
Motorola
Part No.
Description
C159 2113743L21 CAP, 1500pF
C170 2113743L21 CAP, 1500pF
C171 2113743N12 CAP, 2.7pF
C172 2113743L21 CAP, 1500pF
C201 2113740F59 CAP, 220pF
C202 2109445U52 CAP, 62pF
C203 2109445U13 CAP, 2.7pF
C204 2113743L09 CAP, 470pF
C205 Not_Placed CAP, 2.7pF
C206 Not_Placed CAP, 1000pF
C207 2113743L09 CAP, 470pF
C208 2113743L09 CAP, 470pF
C209 2113743L09 CAP, 470pF
C210 2113743L09 CAP, 470pF
C211 2113743E20 CAP, 0.1uF
C212 2113743F18 CAP, 2.2uF
C213 2113743L41 CAP, .01uF
C214 2113743L17 CAP, 1000pF
C215 2113743F18 CAP, 2.2uF
C216 2113743E20 CAP, 0.1uF
C217 2113743L17 CAP, 1000pF
C218 2113743F18 CAP, 2.2uF
C219 2113743E20 CAP, 0.1uF
C220 2113743N34 CAP, 22pF
C221 2113743L41 CAP, .01uF
C222 2113743L41 CAP, .01uF
C223 2113743L41 CAP, .01uF
C224 2113743L41 CAP, .01uF
C225 2311049A57 CAPP, 10uF
C226 2311049A57 CAPP, 10uF
C227 2113743L17 CAP, 1000pF
C228 2113743E20 CAP, 0.1uF
C230 2113743F18 CAP, 2.2uF
C231 2113743L17 CAP, 1000pF
C232 2113743E20 CAP, 0.1uF
C233 2311049A56 CAPP, 4.7uF
C241 2113743L19 CAP, 1200pF
C243 2113741M69 CAP, 0.1uF
C244 2113741F27 CAP, 1200pF
C245 2311049A08 CAPP, 1uF
C251 2113741F49 CAP, .01uF
C253 2109445U38 CAP, 16pF
C254 2109445U15 CAP, 3.3pF
C255 2109445U39 CAP, 18pF
C256 2109445U27 CAP, 10pF
C257 2109445U46 CAP, 36pF
C258 2113743L19 CAP, 1200pF
C263 2109445U43 CAP, 27pF
C264 2109445U19 CAP, 4.7pF
C265 2109445U37 CAP, 15pF
C266 2109445U27 CAP, 10pF
Circuit
Ref
Motorola
Part No.
Description
C267 2109445U46 CAP, 36pF
C268 2109445U13 CAP, 2.7pF
C269 2113743L21 CAP, 1500pF
C270 2113743L19 CAP, 1200pF
C271 2113743L41 CAP, .01uF
C272 2113743E20 CAP, 0.1uF
C273 2113743L41 CAP, .01uF
C274 2113743E20 CAP, 0.1uF
C275 2113743L19 CAP, 1200pF
C276 2113743N19 CAP, 5.1pF
C277 2113743L19 CAP, 1200pF
C281 2113743L19 CAP, 1200pF
C282 2113743N25 CAP, 9.1pF
C283 2113743L19 CAP, 1200pF
C284 2113743L19 CAP, 1200pF
C285 2113743E20 CAP, 0.1uF
C286 2113743N27 CAP, 11pF
C290 2113743N43 CAP, 51pF
C291 2113743N39 CAP, 36pF
C292 2113743L19 CAP, 1200pF
C301 2113743L07 CAP, 390pF
C302 2113743L07 CAP, 390pF
C303 2311049A97 CAPP, 33uF
C304 2113743L41 CAP, .01uF
C305 2113743N50 CAP, 100pF
C306 2113741F49 CAP, .01uF
C310 2113743L41 CAP, .01uF
C311 2113743E05 CAP, .018uF
C312 2311049A57 CAPP, 10uF
C313 2113743L41 CAP, .01uF
C314 2113743L19 CAP, 1200pF
C315 2113743L19 CAP, 1200pF
C316 2113743L19 CAP, 1200pF
C320 2113743E05 CAP, .018uF
C321 2311049A57 CAPP, 10uF
C322 2113743L41 CAP, .01uF
C323 2113743N54 CAP, 150pF
C331 2113743L41 CAP, .01uF
C333 2113743L41 CAP, .01uF
C334 2311049A57 CAPP, 10uF
C400 Not_Placed CAP, .022uF
C401 2113743M24 CAP, 0.1uF
C402 2113743L17 CAP, 1000pF
C403 2113743L17 CAP, 1000pF
C404 2113743L17 CAP, 1000pF
C405 2113743L17 CAP, 1000pF
C406 2113743L17 CAP, 1000pF
C407 2113743L17 CAP, 1000pF
C408 2113743L17 CAP, 1000pF
C409 2113743L17 CAP, 1000pF
C410 2311049A57 CAPP, 10uF
Circuit
Ref
Motorola
Part No.
Description
