Motorola EP450

6-22 VHF 146-174 MHz PCB 8486342Z13-C Schematic Diagrams, Overlays, and Parts Lists
November 24, 2003 HKLN4216A
* Motorola Depot Servicing only
VHF (146-174 MHz) Keypad Board Parts List
VR301 4813830A33 MMBZ5250B
VR302 4813830A33 MMBZ5250B
VR471 4813830A18 MMBZ5235B
VR472 4813830A09 MMBZ5226B
VR473 4813830A33 MMBZ5250B
VR474 4813830A33 MMBZ5250B
VR475 4880140L20 MMBZ5245B
Y51 4802245J84 TSS2_44_395
Y70 9186145B02 45B02
Y201* 4880114R06 14R06
Y202 Not_Placed 45J68
Circuit
Ref
Motorola
Part No.
Description
C1 NOTPLACED CAP, 150pF
C2 2113740F55 CAP, 150pF
C3 NOTPLACED CAP, 150pF
C4 2113743E20 CAP, 0.1uF
C5 NOTPLACED CAP, 150pF
C6 NOTPLACED CAP, 150pF
C7 NOTPLACED CAP, 150pF
C8 NOTPLACED CAP, 150pF
D1 4809496B11 QSMG-H799
D2 4809496B11 QSMG-H799
D3 NOTPLACED QSMG-H799
D4 NOTPLACED QSMG-H799
D5 NOTPLACED QSMG-H799
D6 NOTPLACED QSMG-H799
D7 NOTPLACED QSMG-H799
D8 NOTPLACED QSMG-H799
D9 4809496B11 QSMG-H799
D10 4809496B11 QSMG-H799
D11 4809496B11 QSMG-H799
J1 09_54548_091
1_9pin
CONN_J
J2 09_52892_289
0_28PIN
CONN_J
R1 0662057A97 RES, 100K
R2 NOTPLACED RES, 13K
R3 NOTPLACED RES, 22K
R4 NOTPLACED RES, 43K
R5 NOTPLACED RES, 130K
R6 0662057A97 RES, 100K
R7 0662057A76 RES, 13K
R8 0662057A81 RES, 22K
R9 NOTPLACED RES, 43K
R10 NOTPLACED RES, 130K
Circuit
Ref
Motorola
Part No.
Description
R11 0662057A41 RES, 470
R12 0662057A41 RES, 470
R13 NOTPLACED RES, 330
R14 NOTPLACED RES, 330
R15 NOTPLACED RES, 330
Circuit
Ref
Motorola
Part No.
Description
