Motorola EP450

VHF 146-174 MHz PCB 8486342Z13-C Schematic Diagrams, Overlays, and Parts Lists 6-21
HKLN4216A November 24, 2003
R64 0662057N06 RES, 20K
R65 0662057N13 RES, 39K
R66 0662057N06 RES, 20K
R67 0662057N06 RES, 20K
R72 0662057M64 RES, 390
R73 0662057M80 RES, 1.8K
R74 0662057M76 RES, 1.2K
R75 0662057N01 RES, 12K
R76 0662057V04 RES, 12K
R77 0662057U99 RES, 8.2K
R78 0662057M70 RES, 680
R80 0662057M91 RES, 5.1K
R81 0662057M74 RES, 1K
R82 Not_Placed RES, 0
R90 0662057M43 RES, 51
R91 0662057M79 RES, 1.6K
R100 0662057M61 RES, 300
R101 0662057M32 RES, 18
R102 0662057M61 RES, 300
R103 0662057M86 RES, 3.3K
R104 0662057A18 RES, 51
R105 0662057M76 RES, 1.2K
R106 0662057M90 RES, 4.7K
R107 0662057M54 RES, 150
R110 0662057M63 RES, 360
R111 Not_Placed RES, 2.7K
R120 0662057C55 RES, 150
R121 0662057C55 RES, 150
R150 0680539Z01 RES, 0.1
R151 0662057A09 RES, 22
R152 0662057V27 RES, 100K
R153 0662057V27 RES, 100K
R154 0662057V27 RES, 100K
R155 0662057V27 RES, 100K
R156 0662057M62 RES, 330
R157 0662057M92 RES, 5.6K
R158 0662057M78 RES, 1.5K
R162 0662057M98 RES, 10K
R202 0662057N27 RES, 150K
R205 0662057M50 RES, 100
R206 Not_Placed RES, 100
R212 0662057C01 RES, 0
R220 0662057M54 RES, 150
R221 0662057M54 RES, 150
R223 0662057M50 RES, 100
R227 0662057N27 RES, 150K
R230 0662057N30 RES, 200K
R243 0662057M81 RES, 2K
R244 0662057M43 RES, 51
R245 0662057M78 RES, 1.5K
R246 0662057N23 RES, 100K
Circuit
Ref
Motorola
Part No.
Description
R247 0662057N33 RES, 270K
R248 0662057M43 RES, 51
R253 0662057M42 RES, 47
R254 0662057M58 RES, 220
R255 0662057U91 RES, 3.9K
R261 0662057N16 RES, 51K
R262 0662057M94 RES, 6.8K
R263 0662057M37 RES, 30
R264 0662057M58 RES, 220
R270 0662057M32 RES, 18
R271 0662057M96 RES, 8.2K
R272 0662057M97 RES, 9.1K
R273 0662057M61 RES, 300
R274 0662057M38 RES, 33
R275 0662057M01 RES, 0
R276 0662057M74 RES, 1K
R280 0662057M94 RES, 6.8K
R281 0662057M97 RES, 9.1K
R282 0662057M71 RES, 750
R283 0662057M56 RES, 180
R284 0662057M62 RES, 330
R286 0662057M01 RES, 0
R310 0662057N23 RES, 100K
R311 0662057N23 RES, 100K
R312 0662057N06 RES, 20K
R313 0662057N06 RES, 20K
R320 0662057V43 RES, 330K
R321 0662057V35 RES, 200K
R322 0662057N23 RES, 100K
R400 Not_Placed RES, 100K
R410 0662057M98 RES, 10K
R411 0662057M72 RES, 820
R412 0662057N23 RES, 100K
R413 0662057N23 RES, 100K
R414 0662057N11 RES, 33K
R415 0662057N11 RES, 33K
R416 0662057N06 RES, 20K
R417 0662057M98 RES, 10K
R418 0662057N23 RES, 100K
R419 0662057M90 RES, 4.7K
R420 0662057V35 RES, 200K
R421 0662057V27 RES, 100K
R422 0662057N23 RES, 100K
R423 0662057N23 RES, 100K
R424 0662057V35 RES, 200K
R425 0662057V27 RES, 100K
R430 0662057N23 RES, 100K
R431 Not_Placed RES, 100K
R432 0662057M01 RES, 0
R433 0662057N23 RES, 100K
R434 Not_Placed RES, 100K
Circuit
Ref
Motorola
Part No.
Description
R440 0662057M90 RES, 4.7K
R441 0662057M90 RES, 4.7K
R442 0662057A33 RES, 220
R443 0662057A27 RES, 120
R445 0662057M90 RES, 4.7K
R446 0662057M98 RES, 10K
R451 0662057N15 RES, 47K
R460 0662057N08 RES, 24K
R462 0662057N08 RES, 24K
R463 0662057N08 RES, 24K
R464 0662057N10 RES, 30K
R469 0662057M26 RES, 10
R470 0662057M82 RES, 2.2K
R471 0662057M82 RES, 2.2K
R472 0662057M70 RES, 680
R473 0662057M70 RES, 680
R474 0662057A37 RES, 330
R475 0662057N29 RES, 180K
R476 0662057N23 RES, 100K
R477 0662057M82 RES, 2.2K
R478 0662057M82 RES, 2.2K
R479 0662057N23 RES, 100K
R480 0662057B47 RES, 0
R481 0662057N23 RES, 100K
R482 0662057N35 RES, 330K
R483 0662057N27 RES, 150K
R484 Not_Placed RES, 2.2K
R485 0662057N23 RES, 100K
R486 0662057N23 RES, 100K
R487 0662057M01 RES, 0
R488 0662057N35 RES, 330K
R489 0662057A96 RES, 91K
R490 Not_Placed RES, 2.2K
R491 0662057M01 RES, 0
R492 0662057N08 RES, 24K
R493 0662057N35 RES, 330K
R494 0662057V43 RES, 330K
R495 0662057M92 RES, 5.6K
R496 Not_Placed RES, 10K
R497 0662057N47 RES, 1MEG
R498 0662057N15 RES, 47K
R499 0662057N33 RES, 270K
R501 0662057M50 RES, 100
R502 0662057M50 RES, 100
R503 0662057M50 RES, 100
R504 0662057M50 RES, 100
R505 0662057M50 RES, 100
R506 0662057M50 RES, 100
R507 0662057M50 RES, 100
R508 0662057N23 RES, 100K
R509 0662057N23 RES, 100K
Circuit
Ref
Motorola
Part No.
Description
R510 0662057N35 RES, 330K
R511 0662057N23 RES, 100K
R512 0662057N27 RES, 150K
R513 Not_Placed RES, 100K
R514 0662057N23 RES, 100K
R515 Not_Placed RES, 0
R516 Not_Placed RES, 0
R517 0662057M01 RES, 0
R518 0662057N31 RES, 220K
R519 0662057N23 RES, 100K
R520 0662057N23 RES, 100K
R521 0662057N23 RES, 100K
S440 4080710Z06 SWITCH
S441 4070354A01 SWITCH
S442 4070354A01 SWITCH
S443 4070354A01 SWITCH
S444 1880619Z02 SWITCH
SH1 2686421Z01 SHIELD
SH40 2686419Z01 SHIELD
SH50 2686423Z01 SHIELD
SH52 2686424Z01 SHIELD
SH100 2686418Z01 SHIELD
SH200 2686424Z01 SHIELD
SH201 2686423Z01 SHIELD
SH250 2686425Z01 SHIELD
SH251 2686425Z01 SHIELD
SH253 2686422Z01 SHIELD
SH400 2686420Z01 SHIELD
SH401 2686420Z01 SHIELD
T41 2580541Z02 XFMR
T42 2580541Z02 XFMR
U51 5186144B01 SA616
U52 5109522E10 TC7W04F
U110 0186438Z01 RA07M1317M_VHF
U150 5113818A01 LM2904
U151 2484657R01 57R01
U201 5185963A27 63A27
U251 5105750U54 50U54
U310 5102478J01 TK71750S
U320 5185963A55 LP2986
U330 5102479J01 TK71730S
U401 5102226J56 MC68HC11FL0
U402* 5102463J64 X25128-2.7
U403 Not_Placed SRM2B256
U404* 5102480J01 AT49LV001N_70VI
U451 5185130C53 30C53
U480 5113818A01 LM2904
U490 5108858K99 TDA8541
U510 5113818A01 LM2904
U511 4802245J54 UMG5
VR110 4813830A82 MM3Z4V3T1
Circuit
Ref
Motorola
Part No.
Description
