Motorola EP450

6-20 VHF 146-174 MHz PCB 8486342Z13-C Schematic Diagrams, Overlays, and Parts Lists
November 24, 2003 HKLN4216A
C411 2113743M24 CAP, 0.1uF
C412 2113743L17 CAP, 1000pF
C413 2113743M24 CAP, 0.1uF
C414 2113743M24 CAP, 0.1uF
C415 2113743L17 CAP, 1000pF
C416 2113743L17 CAP, 1000pF
C417 2113743L17 CAP, 1000pF
C418 2113743M24 CAP, 0.1uF
C419 2113743L17 CAP, 1000pF
C420 2113743L41 CAP, .01uF
C421 2113743L41 CAP, .01uF
C422 2113743L41 CAP, .01uF
C430 2113743M24 CAP, 0.1uF
C431 2113743L17 CAP, 1000pF
C432 2113743M24 CAP, 0.1uF
C433 2113743L17 CAP, 1000pF
C440 2113743L41 CAP, .01uF
C441 2113743L41 CAP, .01uF
C442 2113743L41 CAP, .01uF
C443 2113743L41 CAP, .01uF
C444 2113743L41 CAP, .01uF
C445 2113743L41 CAP, .01uF
C446 2113743L41 CAP, .01uF
C447 2113743M24 CAP, 0.1uF
C451 2113743M24 CAP, 0.1uF
C452 2113743E20 CAP, 0.1uF
C453 2113743E20 CAP, 0.1uF
C454 2113743E20 CAP, 0.1uF
C455 2113743L48 CAP, .022uF
C456 2113743E20 CAP, 0.1uF
C457 2113743E20 CAP, 0.1uF
C458 2113743E20 CAP, 0.1uF
C459 2113743E20 CAP, 0.1uF
C460 2113743E20 CAP, 0.1uF
C461 2113743L17 CAP, 1000pF
C462 2113743E20 CAP, 0.1uF
C463 2113743E20 CAP, 0.1uF
C464 2113743E20 CAP, 0.1uF
C465 2113743L17 CAP, 1000pF
C466 Not_Placed CAP, 470pF
C467 2113743L19 CAP, 1200pF
C470 2113743E20 CAP, 0.1uF
C471 2113743F18 CAP, 2.2uF
C472 2113743E20 CAP, 0.1uF
C473 2113743N54 CAP, 150pF
C474 2113743N54 CAP, 150pF
C475 2113743L48 CAP, .022uF
C476 2113743L48 CAP, .022uF
C477 2113743M24 CAP, 0.1uF
C478 2113743N54 CAP, 150pF
C479 2113743N54 CAP, 150pF
Circuit
Ref
Motorola
Part No.
Description
C480 2113743E20 CAP, 0.1uF
C481 Not_Placed CAP, .01uF
C482 2113743L41 CAP, .01uF
C483 2113743E20 CAP, 0.1uF
C484 Not_Placed CAP, .033uF
C488 2113743L09 CAP, 470pF
C489 2113743L09 CAP, 470pF
C490 2113743L09 CAP, 470pF
C492 2113743F18 CAP, 2.2uF
C493 2113743L17 CAP, 1000pF
C494 2113743F18 CAP, 2.2uF
C495 2113743F16 CAP, 1uF
C496 2113743F16 CAP, 1uF
C497 2113743E20 CAP, 0.1uF
C498 2113743F16 CAP, 1uF
C499 2113743N48 CAP, 82pF
C500 2113743L17 CAP, 1000pF
C501 2113743F16 CAP, 1uF
C503 2113743L17 CAP, 1000pF
C504 2113743L17 CAP, 1000pF
C505 2113743L17 CAP, 1000pF
C506 2113743L17 CAP, 1000pF
C507 2113743L17 CAP, 1000pF
C511 2113740F59 CAP, 220pF
C512 2113743N22 CAP, 6.8pF
C513 2113740F59 CAP, 220pF
C514 2113743N31 CAP, 16pF
C518 2113743E20 CAP, 0.1uF
C519 2113743F16 CAP, 1uF
CR1 4813825A19 MMBD352
CR41 4802246J04 HSMS2829
CR51 4813825A19 MMBD352
D51 4802245J97 DAN235ETL
D52 4802245J97 DAN235ETL
D120 4880973Z02 MA4PH261
D121 4880973Z02 MA4PH261
D201 4862824C03 1SV232
D220 4802233J09 IMN10
D221 4802233J09 IMN10
D251 4805649Q13 1SV228
D261 4805649Q13 1SV228
D262 4862824C01 1SV229
D301 4813833A19 MBRM120ET3
D414 4805129M41 MMBD501
D440 4805729G49 BRPY1204W
D470 4809924D18 RB520S-30
D471 4809924D18 RB520S-30
D491 4805129M41 MMBD501
E451 2480640Z01 BK1005HM471
E452 2480640Z01 BK1005HM471
E453 2480640Z01 BK1005HM471
Circuit
Ref
Motorola
Part No.
Description
E500 2480640Z01 BK1005HM471
F301 6580542Z01 FUSE
FL51 9180022M11 MXF45
FL52 9180468V05 FLTR
FL53 9180469V05 CFWC455E
FL54 9180469V03 CFWC455G
J140 0986428Z01 CONN_J
J301 0986237A02 CONN_J
J460 Not_Placed CONN_J
J470 0985818A01 CONN_J
J471 0980683Z03 CONN_J
J491 2809926G01 CONN_P
L1 2413923C09 IDCTR, 68nH
L2 2413923C09 IDCTR, 68nH
L3 2413923C09 IDCTR, 68nH
L4 2413923C09 IDCTR, 68nH
L21 Not_Placed IDCTR, 39nH
L22 2413926N24 IDCTR, 100nH
L31 2413923C09 IDCTR, 68nH
L32 2413923C09 IDCTR, 68nH
L33 2413923C09 IDCTR, 68nH
L40 2413923C09 IDCTR, 68nH
L41 2413923C09 IDCTR, 68nH
L51 2413926N26 IDCTR, 150nH
L52 2462587V44 IDCTR, 680nH
L53 2113743N52 CAP, 120pF
L54 2413923A25 IDCTR, 1.2uH
L81 2462587N68 IDCTR, 1uH
L100 2413926K32 IDCTR, 560nH
L101 2413926K32 IDCTR, 560nH
L102 2409377M17 IDCTR, 100nH
L103 2409377M31 IDCTR, 30nH
L110 2413926K32 IDCTR, 560nH
L120 2413926K32 IDCTR, 560nH
L121 2462587N49 IDCTR, 47nH
L130 2479990N01 IDCTR, 43.67nH
L131 2479990N01 IDCTR, 43.67nH
L132 2479990N01 IDCTR, 43.67nH
L140 2479990M01 IDCTR, 30.54nH
L211 2413926K32 IDCTR, 560nH
L251 2413926K32 IDCTR, 560nH
L252 2413926K32 IDCTR, 560nH
L253 2409377M17 IDCTR, 100nH
L254 2413923C05 IDCTR, 33nH
L255 2413926K29 IDCTR, 330nH
L262 2413926K32 IDCTR, 560nH
L263 2409377M17 IDCTR, 100nH
L264 2413923C07 IDCTR, 47nH
L265 2413926K29 IDCTR, 330nH
L270 2413926K32 IDCTR, 560nH
L271 Not_Placed IDCTR, 560nH
Circuit
Ref
Motorola
Part No.
Description
L276 2413926N24 IDCTR, 100nH
L281 2413926N22 IDCTR, 68nH
L282 2413926N20 IDCTR, 47nH
L283 Not_Placed IDCTR, 270nH
L291 2413926N17 IDCTR, 27nH
L292 2413926N22 IDCTR, 68nH
L471 2413926K30 IDCTR, 390nH
M140 0286427Z01 ANTENNA_NUT
Q21 4802245J95 BFS540
Q22 4805723X02 UMT1
Q51 4802197J95 PBR941
Q70 4880214G02 MMBT3904
Q100 4802245J95 BFS540
Q150 4880214G02 MMBT3904
Q170 4809939C34 EMB10
Q171 4880048M01 DTC144EKA
Q280 4802245J95 BFS540
Q311 4809579E18 TP0101T
Q312 4809579E18 TP0101T
Q313 4802245J54 UMG5
Q402 4880048M01 DTC144EKA
Q403 4813824A17 MMBT3906
Q410 4802245J54 UMG5
Q440 5180159R01 IMX1
Q470 4805723X02 UMT1
Q471 4802245J54 UMG5
Q472 4805723X02 UMT1
Q481 Not_Placed MMBT3906
Q482 4813824A10 MMBT3904
Q490 4802245J54 UMG5
Q493 4809579E18 TP0101T
Q494 4802245J54 UMG5
Q520 4813824A10 MMBT3904
R20 0662057U97 RES, 6.8K
R21 0662057M54 RES, 150
R22 0662057M94 RES, 6.8K
R23 0662057V11 RES, 22K
R24 0662057M71 RES, 750
R25 0662057M92 RES, 5.6K
R26 0662057M01 RES, 0
R40 0662057M74 RES, 1K
R51 0662057M43 RES, 51
R52 0662057N01 RES, 12K
R53 0662057N11 RES, 33K
R54 0662057M91 RES, 5.1K
R55 0662057M62 RES, 330
R57 0662057M90 RES, 4.7K
R60 0662057M83 RES, 2.4K
R61 0662057N23 RES, 100K
R62 0662057M86 RES, 3.3K
R63 0662057N13 RES, 39K
Circuit
Ref
Motorola
Part No.
Description
