5-1
Chapter 5
Radio Tuning and Programming
5.1 Introduction
This chapter provides an overview of the Customer Programming Software (CPS) and Universal
Tuner which have been designed for use in a Windows 95/98/NT/2000 environment. Both these
software will cover all the functions of a traditional Radio Service Software (RSS) package.
They are available in separate kits as shown below:
Each kit contains an Installation instruction manual.
5.2 Radio Tuning Setup
To tune the radio, you will need a Windows 95/98/NT/2000 PC (personal computer) and a Universal
Tuner. To perform the tuning procedures, the radio must be connected to the PC, RIB (Radio
Interface Box) and Universal Test Set as shown in Figure 5-1.
The Tuner for Version R02.03.0 or higher provides the capability for Temperature Compensation
Data Programming as well as online instructional help text.
To read the Temperature Compensation Data:
1. From the Menu, select Utilities and then select Temp Comp Data Read.
2. The values read are displayed.
To program the Temperature Compensation Data:
1. From the Menu, select Utilities and then select Temp Comp Data Write.
2. Enter the values you want to be programmed.
Description Kit Number
Conventional/LTR Radios CPS 3-Year Subscription Package H5177
